CNJ-5000 Slot Milling Implanting and Testing Integrated Machine
Testing Integrated Machine
Function and application introduction: This machine is automatically controlled by PC program and operated by large LCD. Using multispindles servo system mills slot, sends card and sends module, then seals and tests card. Parameters are adjustable, conveying speed is fast and precision is high. It is suitable for slot milling , implanting and testing processing of standard contact IC card.
Features:1. It incorporates slot milling and cleaning of card, glue laminating and punching conveying of IC module, hot welding and cold welding implanting and IC module testing. 2. It is designed by professional slot milling tongs, which prevents slot milling precision from influence of size and thickness and tolerance of card. 3.Independent three spindles positioning control system drives high speed main axises dynamo slot milling. Parameters of all spindles are sole and adjustable, which prevents slot milling precision from influence of size and thickness and tolerance of card. Slot milling mode is various, which means it can mill one layer for once or mill two layers for once. 4. Professional card amending structure ensures high precision of slot milling and sealing.
5. Using servo dynamo steppingly conveys punching of IC module. Module stepping electric eye automatically
monitor and protects quality of module, if it is bad, it will be cleared away. 6. Using servo dynamo drives imported high precision linear module structure conveys IC module. Precision is
high and working longevity is long.7. Using cold welding technics to seal it after hot welding by several level. Temperature is adjustable, implanting result is well. 8. Special hot welding implanting recycle cooling system is suitable for the implanting of different specifications of hot weld glue..9. Double card and card direction test function will test number and direction of card. If it is wrong, machine will alert and stop.10. Slot milling test function will test whether any card is penetrated, if it is penetrated, machine will alert and stop. 11. PC program controls automatic running, so operating speed is fast,. If anything is error, machine will alarm
automatically and stop. 12. It is designed by double mode structure. (only AMIT 500mode)
Power supply |
AC 380V 50/60 HZ |
Control method |
PC program+servo system |
Total power |
6.5KW |
Slot milling precision |
X/Y: ±0.015mm Z: ±0.010mm |
Air source |
6kg/cm²(no water) |
Implanting precision |
±0.02mm |
Air consumption |
Approx 120L/min |
Temperature control range |
0~400℃(can be set) |
Weight |
Approx 900Kg |
Card specification |
ISO CR80/IEC7810 |
Output |
2000~2500 pcs/h |
Overall dimension |
L2200xW850xH1850 mm |
Testing Integrated Machine wooden case
CNJACKY since 2000, which specializes in reaching, developing and manufacturing smart card making equipments. Equipped with the advanced production lines, professional R&D team and strict quality control system, CNJACKY keeps good reputation on excellent quality, customer focus service.and competitive prices.
CNJACKY always insists on "honesty first, professional concentration, in pursuit of excellent and service forever", and dedicates in technology innovation and product development. It has researched and developed kinds of production equipments for plastic and paper card, contact and contactless IC cards, double-interfaced cards and bank cards. The company always takes the lead in the industry especially in terms of automatic punching machine, automatic card packing machine, automatic IC slot milling machine and automatic chip implanting machines. Its products are highly recognized by the oversea and domestic customers for excellent qualities and reasonable prices.
1.Question: How long time of warranty ?
Answers: 1 year free of charge
2.Question: whole lifetime warranty ?
Answers: chargeable of parts
3.Question: Do you get CE certified ?
Answers: Yes, we get CE certificate for all our machines
4.Question: Can you supply door to door installation service for machines ?
Answers: Yes ,we supply ,buyer need to afford all dinners ,hotels and tickets
