Single Rotary Tableting Machine

Name: Single Rotary Tableting Machine
Brand: Shree Bhagwati Pharma
SKU: 122511923

US$ 4,000 - 12,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Gujarat, India

Brand Name:

Shree Bhagwati Pharma

Shree Bhagwati Pharma Machinery Company

Payment & Shipping

Payment Methods:

Port of Shipment:

Gujarat India

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Gujarat, India

Brand Name Shree Bhagwati Pharma

Model Number SBPD3 - 23,20,16,12

Type Rotary Tablet Press

Production Capacity 57,960/hr

Max. Pressure(KN) 12Tons

Max. Tablet Thickness(mm) 30mm

Max. Tablet Diameter(mm) 16mm

Voltage 220V

Power(W) 4KW

Weight 300kg

Dimension(L*W*H) 30 mm

Certification ISO9001

After-sales Service Provided Engineers available to service machinery overseas

Rotary Tableting Machine

Rotary tableting machine is totally enclosed, i.e. top half of the machine (compression zone) with S.S.hood and acrylic covers and lower half of the machine complete with mat finished S.S.Covers.
This reduces the noise level and to & fro flow of dust between compression zone and M/c room.
Antivibration mounting provided. Hence no foundation required.
Turret is made of highly ductile SG Iron casting.
Lower Punch seals (Optional)
Large paint free compression zone with plenty of space for ease of cleaning & accessibility of components.
Electronic total output counter is provided on the control panel.
Operating system same as our standard model and it is easy to operate and maintain the machine.
Most of the components are common with our standard model which reduces inventory of spares.
Higher Turret speed upto 42 RPM gives higher output than standard machine. (30 RPM for 570 machine)
Friction plate is provided on cam plate to minimise wear & tear of cam track which also facilitates its easy replacement.
Upper punch dust covers are provided to avoid collection of dust on punch head.

Rotary Tableting Machine - Models	SBP3SH - 12	SBPD3 - 16	SBPD3 - 20	SBPD3 - 23
Tooling	Special	"D"	"D"	"D / B" Combined
No. of Stations	12	16	20	23
Max. Output (Tab / hr)*	15,840	40,320	50,400	57,960
Max. Pressure	12 Tons	10 Tons	10 Tons	10 Tons
Max. Tablet Dia	40 mm	25.4 mm	25.4 mm	16 mm
Max. Depth of Fill	30 mm	20 mm	20 mm	17.4 mm
Electricals	3 HP, 3 Ø, A.C	2 HP, 3 Ø, A.C	2 HP, 3 Ø, A.C	2 HP, 3 Ø, A.C.
