Supply High Quality Tungsten Carbide Washer

Supply High Quality Tungsten Carbide Washer thumbnail-1
Supply High Quality Tungsten Carbide Washer photo-1
US$ 20 - 100 MOQ: 5 Kilograms
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
Jiboshi
Model Number:
type01
Contact Supplier Request Quote Chat Now
Zhuzhou Jingzuan Carbide Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
any port in China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hunan, China
Brand Name Jiboshi
Model Number type01
Shaping Mode Die Casting
Product Material Other, tungsten carbide
Product Vehicle Mould

tungsten carbide die blanks for reducing diameter of nuts




we can produce tungsten carbide dies of different sizes and types according to your requests.



[The Features Of various types cemented carbide heading die blanks for making standard bolts]

 1. I  promise my tungsten carbide dies,which are made of high purity tungsten power as the raw material , will not crack;



2.the strenght of  the die core is more than 2200 n/mm3;



3. Long service life:we take the unique formula and add wear-resisting material element into my tungsten carbide dies;



4. Processing costs are lower;



5.  the die core will not take off the moulds;



6. Quick delivery: various models mold is complete, the production cycle fast, even if no inventory spot, 4 days production time of delivery.



[The Grade Of tungsten carbide die blank]

Grade

Equal to ISO Category Number

Performance

Density

Bend Strength

Hardness

G/Cm3

N/mm2

HRA

YG3

K01

14.9-15.3

1180

≥90.5

YG3X

K01

15.1-15.4

≥1300

≥91.5

YG6X

K10

14.8-15.1

≥1560

≥91.0

YG6A

K10

14.7-15.1

≥1580

≥91.0

YG6

K20

14.7-15.1

≥1670

≥89.5

YG8

K20-K30

14.6-14.9

≥1840

≥89



[Defferents Type Of  Die blanks]

Type

Dimensions (mm)

D

d

H

α

β

γ

01

6~8

0.2

4~6

10°

40°

60°

10

6~8

0.4~0.8

4~6

40°

-

11

8~22

0.4~5.7

6~20

10°~40°

40°

12

8~26

0.4~8.0

6~16

16°

40°

13

30~140

3.7~84

21~50

14°~20°

-



Tungsten carbide washer  Grade Recommend

Grade

Density g/cm3

Hardness HRA(hv)

T.R.S(M Pa)

Performances &applications recommended

YG6

14.9

89.5

2150

Good Wear resistance, used for hard wood,processing original wood,

aluminum section bar,brass rod and cast iron.

YG8

14.6

89

2320

Suitable for the roughening of cast iron and light alloys and also for the milling

 of cast iron and low-alloy steel.

YG11

14.4

87.5

2260

Medium grain, for wear parts and mining tools

YG15

14.1

86.5

2400

Medium grain, for mining tools, cold heading and punching dies

YS2T

14.45

92.5

    2800

Fine carbide,high wear resistance,high bending strength,high resistance to

bonding, high thermal strength.Machining of refractory alloys,

stainless steel and high manganese steel etc.Mainly used for disc cutter

 and other tools

YL10.2

14.5

92.5

3400

Wear resistance and strength comparatively higher,suitable for processing cast iron,
 non-ferrous metal and non-metalloid materials.

YNi8

14.6

88.5

1710

This grade with 8% nickel binder, it has good wear resistance&

 corrosion resistance performance ,

especially used for high pressure environmental ,

 also good for cutting the titanium alloy.





Supply high quality tungsten carbide washer



[About Us]

    Zhuzhou JingZuan Carbide Co., Ltd is the only modern high-tech enterprises who concentrates on reseaching, developing producing and selling grade A of GB advanced tungsten carbide products.With high-purity cemented carbide podwer, high-precision equipment and seven levels strict quality test system, These features make our products superior than other products,so that ourproducts are exported to southeast Asia and the Americas and enjoy a high popularity in those markets.



[Any question or requirement , please contact us]



Sales: Ms.Bigel Wu
Skype:  haocarbide
Tel: 86 731 22031856
Mob: 86 15273315755
