Yamatake flowmeter converter manufacturer
1. The product function introduction
1.1Basic function
Low-frequency square-wave exciting,exciting frequency:1/16 power frequency,1/20power frequency,1/25 power frequency;
High-frequency square-wave exciting,exciting frequency:1/2 power frequency(for grouting liquid measure);
Exciting current can be selected for 125mA,187.5mA,250mA,500 mA;
No need to add empty pipeline measurement, and can measure continuously, alarm by fixed value;
Current speed range:0.1 --- 15m/s,current speed resolution:0.5mm/s;
AC high-frequency switching power,range of voltage:85VAC --- 250VAC;
DC 24V switching power,range of voltage:20VDC --- 36VDC;
Network function:MODBUS,GPRS,PROFIBUS ,HARTcommunication interface(choose);
Chinese or English displaying mode, (other languages can be set);
Three integrator gross inside, respective register: Forward gross, reverse gross and minus value gross.
1.2Especial function
Recording time when power turn-off, to record power broken time of instrument system automatically and recruit to count the missing flux;
Recording function of hour gross, to record the flux gross by hour, fit for timed measure;
Infrared handing telecontrol keyboard,all the functions of far-untouched controlling converter.
1.3 Normal operating conditions
Ambient Temperature Ranges:fission –10~+60°C;
Relative Humidity:5%~90%;
Power Supply: 85~250V,45~63Hz ( single-phase AC).
Dissipation Power: <20W( After connecting sensor).
1.4 Type of connecting with sensors
The integrated circinal shells: circinal shells, shells connect with the flange directly, explosion-proof;
The integrated squared shells: squared shells, shells connect with the flange directly;
The split squared shells: squared shells (hang on the wall), Signal converters connect with cable of sensor;
The total area of our company is 15000 square meters,and the building area is 6000 square meters.Our company have five utility model patents,three software copyrights.And we also have production qualification and liquid calibration settings for flow meters from Dn25mm to DN2000mm.We have strong R&D capability.Our company and our head office have large quantity of running water industrial users,and we also have strong marketing capabilities on battery powered electromagnetic flow meter.We are expecting to cooperate with manufacturer who can provide battery powered flow converter,or through expand cooperation in various modes.To develop the Chinese market and international market of battery powered flow meter together.To learn from each other and to achieve win-win situation.
We are expecting sincere cooperation.If you have interest,please feel free to contact us at any time.We are looking forward to hearing from you.
