Home > Packaging & Printing > Packing Machinery > Packing Line > YET04-01 Automatic Duplex Slitter

YET04-01 Automatic Duplex Slitter

Name: YET04-01 Automatic Duplex Slitter
Brand: yuerte
SKU: 122459999
Availability: InStock

YET04-01 Automatic Duplex Slitter thumbnail-1

YET04-01 Automatic Duplex Slitter photo-1

US$ 15,000 - 30,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Application:

Other, Machinery & Hardware

Packaging Type:

Cartons

Contact Supplier Request Quote Chat Now

Suzhou Yuerte Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Application Other, Machinery & Hardware

Packaging Type Cartons

Packaging Material Paper

Automatic Grade Automatic

Driven Type Electric

Power 5.5kw

Place of Origin Jiangsu, China

Brand Name yuerte

Model Number YET04-01

Specifications

1.slit BOPP tape and stationery tape.
2.slitting width:25-1320mm.
3.speed:0-180m/min.
4.max. feeding diameter:1000mm.

1.application:

Suitable for BOPP adhesive tape/stationery tape.

2.feature:

(1).YET04-01 Automatic Duplex Slitter---centralized control of all buttons , easy operation.

(2).the unwinding wheel is arch design,and wipes out the wrinking of adhesive tape in the process of feeding.

(3).YET04-01 Automatic Duplex Slitter----equipped with industrial blade (air blade)which suitable for the slitting of BOPP tape.

(4).the leftover material winding could wag,reducing the time of leftover material changing of lap,and raising of efficiency.

(5).oil pressure feeding nechanism could feed rapidly and reduce the labor intensity.(optional)

(6).stationery tape slitter rewinderautomatic labeling mechanism , improve economic performance.(optional)

(7).feeding mechanism install with partition hood, reduce spool-out noise of the material to achieve an ideal working condition.

nical parameters:

Raw material width	1020,1320,1620mm
Max. feeding diameter	Φ1000mm
Slitting width	25-1320mm
Max. rewinding diameter	200mm(max.)
Inside diameter of paper core	Φ25mm,Φ38mm,Φ76mm
Max .rewinding speed	0-180m/min
Working air pressure	6 bar
Main motor	5-10 HP stepless speed changing motor

4.Autospray type feedwater is adopted in the cooling system

All of the machine panel use the baking varish craft

5.warranty:

The Warranty Period for the contract equipment shall be 12 months from the next day after the end of commissioning. If the supplied equipment is found to be defective as a result of faulty materials or workmanship within the Warranty Period, the Seller shall, at its own expenses, rectify or replace defected part of the equipment,the transportation fee for the replace components from the Seller's factory to the buyer's country shall be borne by the seller, the transportation fee for the replaced components from the buyer's country to the Seller's country shall be the Buyer. Wearing parts and damages due to incorrect operation are not included in the Warranty scope.
