bopp tape coating machine

Specifications

1.suitable for bopp adhesive tape.
ating average.
3.operation stability.
4.high efficiency.

1.Application-

 suitable for the bopp adhesive tape

2.feature:

1) straight-scraping transfer-printing type gluing,stablility in performance,even gluing.

2) high-speed production of 90-180M/MIN

3) lifting unwinding,double rewinding.

4) high-speed automatic cutting cloth and connecting film.

5) tension controlling by segmentation.

6) the temperature could be controlled by segmentation and adjusted according to the technical process.

7) slit nozzle blasting dry syetem for bake oven,hign in drying efficiency.
3.Technical parameters:

	Model	YET-500		YET-1000	YET-1300		YET-1600
	Valid width	500 mm		1000 mm	1300 mm		1600 mm
	Machine speed	5-30m/min		5-80m/min	15-180m/min		15-180m/min
	Coating Average Degree	±0.015 mm
	Rewinding Edge Smooth	±2 mm
	Max. power	5-25 HP	20-45 HP			30-80 HP		40-100 HP
	Oven Length	Customer design upon request available
	Heating	/// Steam/Hot blast/Thermal Oil/ Electric
/	Voltage	380V  50Hz
