pmr 446 walkie talkie BAOFENG UV-B6 two way radio BAOFENG UV-B6 two way radio walkie talkie
Quick Details
- Place of Origin: China (Mainland)
- Brand Name: BAOFENG
- Model Number: UV-B6
- Type: Handheld
- Dimensions: 116.2mm*57.9*mm*35.7mm
- Frequency Range: 136-174&400-480mhz
- Storage Channel: 99
- Talk Range: 5-10km
- Product Name: Walkie talkie
- Model NO.: BF UV-B6
- Color: Black
- R.FPOWER Rating: 5W
- Opertate Voltage: 7.4V
- Standard Battery: 1800MAh Li-ion
- Standard Accessory: AntCharger,Battery ,1 dual band enna,Hang Strap, Belt Clip
- Weight: 0.8kg
- Shippment terms: EMS,DHL,TNT,Fedex
- Delivery time: 5-7days
Packaging & Delivery
| Packaging Details: | UV-B6 coming with box package |
|---|---|
| Delivery Detail: | 2-3days |
<:article id=richTextContainer>
Specifications
walkie talkie two way radio for UV-B6
1.Output power:5w
2.Frequency:136-174&400-480mhz
3.VOX functions
4.99 channel
New 5w portable high power output BAOFENG walkie talkie two way radio UV-B6
MAIN FEATURES AND FUNCTIONS:
-Dual Watch
-Priority Channel Scanning
-VOX/FM Radio Built-in
-Emergency Alarm
-Call Tone (1750Hz)
-Battery Save
-High Illumination Flashlight
-DTMF Encoded
-CTCSS/DCS
-PTT ID
-Voice
SPECIFICATIONS
General
Frequency Range :UHF 400-480MHz VHF 136-174MHz(dual band)
Channel Capacity: 99
Channel Spacing :5/6.25/10/12.5/20/25KHz
Operated Voltage: 7.4V
Battery Capacity: H-1800MAh Li-ion
Battery Life: (5-5-90 duty cycle) About 10 hours
Frequency Stability :±2.5ppm
Operated Temperature: -20°C+60°C
Antenna Impedance :50Ω
Dimensions :116.2mm×57.9mm×35.7mm
Transmitter
RF Power Output: 4W/1W
Modulation:F3E
Spurious and Harmonics
Spurious Emission: 65dB
FM Noise :45dB(W) <42dB (N)
Audio Distortion: <5%
Transmitting Current: <1.3A
Receiver
Sensitivity: (12dB SINAD) <0.20 uV
Selectivity: 60dB/55dB
Intermodulation: >65dB
Adjacent Channel Selectivity: >65dB
Spurious Response: >60dB
FM Noise: 45dB(W) /42dB (N)
Audio Power Output: 1000mW
Audio Distortion: <5%
1,5 Watts output power
2,Dual band dual display dual standby
3,5-10 km talk range
4,2000mAh Li-ion battery
5,7.4V Operated Voltage
6,136-174 & 400-470MHZ
pmr 446 walkie talkie BAOFENG UV-B6 two way radio Specifications:
Item number |
UV-B6 |
General | |
Frequency Range |
65-108MHz(only commercial FM radio reception) |
VHF:136-174MHZ, UHF 400-470HZ (TX/RX) | |
Memory channels: |
Up to 99 channels |
Frequency Stability |
±2.5ppm |
Frequency Step: |
5kHz/6.25kHz/10kHz/12.5kHz/20kHz/25kHz |
Antenna Impedance |
50Ω |
Operating Temperature |
-20 to +60 ‘C |
Supply voltage |
Rechargeable Lithium-lon 2000mAh 7.4V |
Mode of operation |
Simple or semi-duplex |
Dimension(W x H x D) |
116.2 x 57.9 x 35.7 mm |
Weight |
549g(including battery, antenna) |
Transmitter | |
Output power |
5W / 1W |
Adjacent Channel Power |
45dB/42dB |
Maximum deviation |
<±5kHz(Wide) / <±2.5kHz(Narrow) |
Spurious Radiation |
<7.5μW |
Adjacent Ch. power |
≤-65dB / ≤-60dB |
Receiver |
|
Receiver sensitivity |
-122dBm(at 12 dB SINAD) |
Intermediation |
65dB |
Audio output |
1W |
Adjacent channel selectivity |
65dB/60dB |
Spurious response |
65dB |
Receiving current |
≤380mA |
Each set package including:
1*Newest BaoFeng UV-B6 Radio
1*1800mAh high capacity Li-ion battery
1*Dual band Antenna
1*Intelligent Charger(EU,US,UK,AU and Japan Plug and adaptor all available)
1*Wrist Strap
1*English Manual Book
|
|
|
|
