In Building DAS Repeater Booster 900 1800 Mobile Repeaters GSM Signal Boosters

Product Description
In Building DAS Repeater Booster 900 1800 Mobile Repeaters GSM Signal Boosters in mobile communication repeaters would be an optional solution to cover areas that can not be covered by base stations.
Kingtone Dual Band GSM Repeater is an ideal solution for operators in more than one system and more than one sub bands.
The Dual Band GSM Repeater is working as a relay between the BTS and Mobiles. It picks up the signal from the BTS via the dual-band Donor Antenna, linearly amplifiers the signal and then retransmits it via the dual-band coverage antenna or the dual-band indoor signal distribution system to the weak and blind coverage area. And the mobile signal is also amplified and retransmitted to the BTS via the opposite direction.
In Building DAS Repeater Booster 900 1800 Mobile Repeaters GSM Signal BoostersIn Building DAS Repeater Booster 900 1800 Mobile Repeaters GSM Signal Boosters
Main Features:
1) Application in entire edifice indoor used or large area outdoor coverage;
2) Cover about  1~15km without block or obsturct;
3) High linear design, lower interference to BTS;
4) High efficient fasion radiator, high-preformance waterproof chassis, application for outdoor;
5) ALC function desgined;
6) Manual gain control function;
7) Various repeaters with low MOQ;

Technical Specification:
  Dual Band GSM Repeater

Specification

GSM 900

GSM 1800

Frequency

Downlink

890 ~ 915MHz

1710~ 1785MHz

Uplink

935 ~ 960MHz

1805 ~ 1880MHz

RF Output Power

Downlink

Max +20dBm

Max +20dBm

Uplink

Max +15dBm

Max +15dBm

Gain

+60dB ±2dB

+60dB±2dB

Pass Band Ripple

d 4dB

d 4dB

Delay

< 5us

< 5us

ALC Level

Downlink

18~20dBm/Total

18~20dBm/Total

Uplink

13~15dBm/Total

13~15dBm/Total

ALC Ranges

30dB min

30dB min

Shut down level

Downlink

21~23dBm/Total

21~23dBm/Total

Uplink

16~18dBm/Total

16~18dBm/Total

Noise Figure

 Max 8dB

 Max 8dB

VSWR

1:1.5 max

1:1.5 max

Size

TBD

Power

AC100V ~ 220V ±10% (50/60Hz) WITH ADAPTOR

Power Consumption

< 50W

Operating Temp& Humidity

-10 ~ +40 / 5% ~ 95% RH

ALARM DISPLAY

3 LED :  GREEN=POWER ON, GSM 900 RED=S/D ,

DCS1800,  RED=S/D

Connector

N (Female
Detailed Images



 In Building DAS Repeater Booster 900 1800 Mobile Repeaters GSM Signal BoostersIn Building DAS Repeater Booster 900 1800 Mobile Repeaters GSM Signal BoostersIn Building DAS Repeater Booster 900 1800 Mobile Repeaters GSM Signal BoostersIn Building DAS Repeater Booster 900 1800 Mobile Repeaters GSM Signal BoostersIn Building DAS Repeater Booster 900 1800 Mobile Repeaters GSM Signal Boosters

Application

Kingtone In Building DAS Repeater Booster 900 1800 Mobile Repeaters GSM Signal Boosters to expand signal coverage of signal blind areas where signal is weak or unavailable.

1. Small building indoor covertage

2. High building covertage

3. Tunnel covertage

4. Subway covertage

5. Vehical covertage

 6.basement room coverage

In Building DAS Repeater Booster 900 1800 Mobile Repeaters GSM Signal Boosters
