KINGTONE Remote Control Signal Repeaters 900 2100 mhz GSM Repeater 3G
KINGTONE Remote Control Signal Repeaters 900 2100 mhz GSM Repeater 3G is designed to solve problems of wak mobile signal, which is much cheaper than adding a new base station (BTS).Main operation of the repeaters are to receive lower-power signal from BTS via RF transmission and then transmit the amplified signal to the areas where network coverage is inadequate.And the mobile signal is also amplified and transmitted to the BTS via the opposite directon.
Features:
1,Output Power +30dBm - +43dBm for large coverage application;
2,High working gain as Min. 95dB;
3,Adopting filter with highly selectivity and low insertion loss eliminates interference between uplink and downlink;
4,RS232 ports provide links to laptop for local setting and monitoring by built-in web interface;
5,Built-in wireless modem (Option) for remote monitoring by SMS or GPRS;
6,Details repeater parameters and status can be monitoring by Control Panel, such as temperature, output power level, gain, ATT, return loss, VSWR etc;
7,Support upgrading firmware remotely by GPRS;
8,High gain linear power amplifier technique with reliable performance;
9,Compact size and light weight, easy to install on wall or pole;
KINGTONE Remote Control Signal Repeaters 900 2100 mhz GSM Repeater 3G
GSM900 2100 mhz Cell Phone Signal Amplifier Signal Booster 2G 3G
GSM900 2100 mhz Cell Phone Signal Amplifier Signal Booster 2G 3G
Typical Application:
KINGTONE Remote Control Signal Repeaters 900 2100 mhz GSM Repeater 3G
to expand signal coverage of signal blind areas where signal is weak or unavailable.
1. Small building indoor covertage
2. High building covertage
3. Tunnel covertage
4. Subway covertage
5. Vehical covertage
6.basement room coverage
Technical Specification:
Type |
KINGTONE Remote Control Signal Repeaters 900 2100 mhz GSM Repeater 3G |
||||
Frequency |
900/2100MHz GSM WCDMA Cellphone Repeater |
||||
Output Power |
33dBm |
37dBm |
40dBm |
43dBm |
|
Gain |
50-65dB |
||||
Gain Adjust Range |
≥30dB;1dB/step |
||||
AGC Range |
≥25dB |
||||
IMD3 |
≤-50dBc |
≤-45dBc |
|||
Noise Figure |
≤5dB |
||||
Ripple in Band |
≤3dB |
||||
Time Delay |
≤10μs |
||||
Spectrum mask |
Meet ETSI specification |
||||
Spurious Emission |
9KHz-1GHz:≤-36dBm/30KHz;1GHz-12.75GHz:≤-30dBm/30KHz |
||||
Port Impedance |
50Ω |
||||
VSWR |
≤1.5 |
||||
Monitoring Mode |
Local;Remote(Optional) |
||||
Power Supply |
AC220V(Normal); AC110V or DC48V or Solar Powered(Optional) |
||||
Weight |
21kgs |
21kgs |
26kgs |
32kgs |
|
Software |
Standard |
||||
Local Monitoring |
PC via USB Port |
||||
Remote Monitoring |
Via SMS or GPRS Modem |
||||
Controlled Parameters |
Gain, Frequency, Repeater ON/OFF, Alarm Enable, etc. |
||||
Monitoring Parameters |
Gain, Frequency, Repeater ON/OFF, Alarm Message. |
||||
Alarm Items |
Repeater Failure, DC Failure, ALC Alarm, PLL Failure. |
||||
Mechanical Specifications:
| Weight | 25kg | 25kg | 35kg | 35kg |
| Dimension | 590*370*250 mm | 670*420*210 mm | ||
| Installation mode | Wall installation(normal);Pole installation(optional) | |||
| Connector | RF:N female; Optical:FC/APC | |||
Case |
IP65(Slave) |
Temperature |
-25~+55°C(Slave) 0°C~+55°C(Master) |
Humidity |
5%~95% (Slave) |
We are a global mobile signal repeater/amplifier/booster manufacturer in China for more than 10 years experience. We can do as below for your best reference:
Our present manufacturing service:
1) GSM/CDMA/WCDMA/IDEN/DCS/PCS/LTE and other Repeater, including:
1. Single band Repeater
2. Dual Band Repeater
3. Tri band Repeater
4. Optic Fiber Repeater
5. Wide Band Repeater
6. Channel Selective Repeater
7. ICS Repeater
2)All kind of Repeater Accessories, including:
1.Antenna
2.Splitter
3.Connector
4.Cable
5.Functional Modules
Signal System |
Frequency Range |
Output Power |
GSM900MHz Repeater |
Uplink:890-915MHz Downlink:935-960MHz |
Indoor:15dBm, 17dBm, 20dBm,23dBm Outdoor:33dBm,37dBm,40dBm,43dBm |
DCS1800MHz Repeater |
Uplink:1710-1785MHz Downlink:1805-1880MHz |
Indoor:15dBm, 17dBm, 20dBm,23dBm Outdoor:33dBm,37dBm,40dBm,43dBm |
GSM850MHz Repeater |
Uplink:824-849MHz Downlink: 869-894MHz |
Indoor:15dBm, 17dBm, 20dBm,23dBm Outdoor:33dBm,37dBm,40dBm,43dBm |
CDMA450MHz Repeater |
Uplink:450-457.5MHz Downlink:460-467.5MHz |
Indoor:15dBm, 17dBm, 20dBm,23dBm Outdoor:33dBm,37dBm,40dBm,43dBm |
CDMA800MHz Repeater |
Uplink:824-849MHz Downlink:869-894MHz |
Indoor:15dBm, 17dBm, 20dBm,23dBm Outdoor:33dBm,37dBm,40dBm,43dBm |
PCS1900MHz Repeater |
Uplink:1880-1890MHz Downlink:1960-1970MHz |
Indoor:15dBm, 17dBm, 20dBm,23dBm Outdoor:33dBm,37dBm,40dBm,43dBm |
3G 850MHz Repeater |
Uplink: 824-849MHz Downlink:869-894MHz |
Indoor:15dBm, 17dBm, 20dBm,23dBm Outdoor:33dBm,37dBm,40dBm,43dBm |
UMTS2100MHz |
Uplink:1920-1980MHz Downlink:2110-2170MHz |
Indoor:15dBm, 17dBm, 20dBm,23dBm Outdoor:33dBm,37dBm,40dBm,43dBm |
GSM900/1800MHZ |
890-915MHz/935-960MHz |
Indoor:15dBm, 17dBm, 20dBm,23dBm Outdoor:33dBm,37dBm,40dBm,43dBm |
1710-1785MHz/1805-1880MHz |
|
Anna Yao
|
|
Quanzhou Kingtone Optics & Electronics Technology Co., Ltd
Add:3th Floor,Bld B,Yucheng Base, Keji Road,Fengze district ,Quanzhou ,Fujian,China.
|
|
Tell: +86 595 28857992 Fax: +86 595 22155502 Whatsapp: +86 13178207380 skype: anna.yao696 Web: |
For more details of KINGTONE Remote Control Signal Repeaters 900 2100 mhz GSM Repeater 3G,welcome you to contact us now!
