mini GSM mobile Signal Booster for indoor coverage 900mhz
gsm mobile signal booster (also named repeater or booster) is a product designed to solve the mobile phone blind or weak signal. Inside of some tall buildings, the basement of some places such as malls , restaurants , places of entertainment such as Karaoke OK sauna and massage, subway stations and many other places where cell phone signals can not reach and can not use the phone. Cell phone signal amplifier can solve these problems. In a particular place as long as installing a mobile phone repeater , the mobile signal can be well boosted and the mobile phone can be well used.Making you keep in touch with others smoothly in everywhere
Application:
This product is suitable for operation of mobile phones in a weak signal area!
Features:
1.High syste m gains
2.Full duplex and double-end design, external power supply, and convenient installation
3.ALC technology with auto-steady function adopted.
4.Provide power indication and uplink and downlink indications.
5.With the amplified linear power, the intermodulation and spuriousness are suppressed effectively.
6.The reliability conforms to GB6993-86 standards.
7.The electromagnetic compatibility conforms to ETS300 609-4 standards ,etc.
Technical Specification:
|
Model
|
KT-9050
|
KT-9060 |
KT-9070 |
|
Frequency range |
Uplink 890-915MHz |
|||
Downlink 935-960MHz | ||||
|
Model
|
KT-8050
|
KT-8060 |
KT-8070 |
|
Frequency range |
Uplink 824-849MHz |
|||
Downlink 869-894MHz | ||||
|
Gain (dB) |
Uplink |
Gp≥45 |
Gp≥55 |
Gp≥65 |
Downlink |
Gp≥50 |
Gp≥60 |
Gp≥70 |
|
Output power |
≥17dBm |
≥17dBm |
≥20dBm |
|
Pass band ripple |
≤5dB |
|||
Guard band rejection |
(BW-60dB)≤42MHz , (BW-70dB)≤45MHz |
|||
I/O impedance |
50Ω/N Connector |
|||
I/O return loss |
≤-8dB |
|||
Noise figure |
≤-8dB |
|||
Intermodulation attenuation(Po=13dBm) |
≤-40dBc |
|||
Transmission |
≤0.5μs |
|||
Ambient |
-10°C~50°C |
|||
Power supply |
AC110~240V±10% 45~55Hz 5V 3A |
|||
Reliability |
To the GB6993-86 standard |
|||
Electromagnetic |
To the ETS300 694-4 standard |
|||
Function |
a) Power supply LED denote b) Export power LED denote |
|||
RF Connector |
N-Female |
|||
Size |
135mm×85mm×28mm |
|||
Size(KT-90/8070) |
150mm×85mm×28mm
|
|||
Weight |
< 0.8 Kg / (KT-90/8070 <1.2 Kg) |
|||
Frequency range list for our repeaters :
Support System |
Frequency Range |
Output Power |
GSM900MHZ |
890-915MHz/935-960MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
DCS1800MHz |
1710-1785MHz/1805-1880MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
PCS1900MHz |
1895-1910MHz/1975-1990MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
GSM850MHz |
824-849MHz/869-894MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
CDMA450MHz |
450-457.5MHz/460-467.5MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
CDMA800MHz |
824-849MHz/869-894MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
CDMA1900MHz |
1880-1890MHz/1960-1970MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
UMTS850MHz |
824-849MHz/869-894MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
UMTS2100MHz |
1920-1980MHz/2110-2170MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
GSM900/1800MHZ |
890-915MHz/935-960MHz 1710-1785MHz/1805-1880MHz |
2W/5W/10W/20W/ |
GSM850/1900MHZ |
824-849MHz/869-894MHz 1880-1890MHz/1960-1970MHz |
2W/5W/10W/20W |
GSM900/UMTS2100 |
890-915MHz/935-960MHz 1920-1980MHz/2110-2170MHz |
2W/5W/10W/20W/ |
Our repeater support above frequency range .
Our present manufacturing service:
1. Single-band repeaters of LTE/GSM/CDMA/PCS/DCS/WCDMA
2. Dual-band repeater of GSM/DCS; GSM/WCDMA; CDMA/PCS;
3. Tri-band repeater of GSM/DCS/WCDMA
4,Trunk Amplifier
5. All kind of Antenna/Splitter/Connector/Cable
Question: I work in an office building where my cell phone coverage in certain areas, including my office, is non-existent or spotty at best. How can I improve my coverage?
Answer: The requirement for reliable, always-on cell phone coverage within the office environment is increasing dramatically. It is not unusual to encounter trouble spots within a building where cell phone signals are weak or non-existent.
Kingtone repeater provides affordable and clear coverage to those trouble spots. The unit can be easily deployed and provides a coverage range of up to 100,000 square feet. Multiple units can be easily deployed to cover office areas and working locations.
Kingtone repeater can be deployed even without access to the roof or outside.
Welcome to OEM !
1. Q: What is MOQ(mini Order Quantity)
A: In general, it is 100pcs. According situation, it is negotiable.you can also place sample order.
2. Q: do you accept Customized?
A: yes,we did produce as customer requirement ,OEM & ODM are welcomed.MOQ of customized order should be 1000pcs
3. Q: Could you offer free sample to test?
A: Yes, sure. For regular VIP agency we offer free sample when New Products Launch,for New customer you pay the sample fee first when your Order reach required amount we minus the sample Cost for you.
4. Q: What payment terms you can accept ?
A: We support TT /Western Union /Paypal
Welcome to our website : for more updated information .
welcome you to visit our company website: , for more information .
My contact info :
Kingtone, connecting the world seamlessly !
|
|||||
| |||||
|
