Specifications
Outdoor 3g 2100mhz Solar Power or Battery Wireless Repeater Cell Phone Mobile Signal RepeaterOutdoor 3g 2100mhz Solar Power or Battery Wireless Repeater Cell Phone Mobile Signal Repeater
PS :
Our present manufacturing service:
1) GSM/CDMA/WCDMA/IDEN/DCS/PCS/LTE and other Repeaters (Fullband/ Dual band/ Tri band/Optic Fiber/ Band or frequency selective /Frequency Shifting) and series Trunk Amplifiers.
2)All kind of Antenna/Splitter/Connector/Cable/Functional Modules
3)Welcome to further discuss!!!
Wireless Wideband Repeater Description:
Kingtone GSM Wireless Repeaters system is designed to solve problems of weak mobile signal, which is much cheaper than adding a new Base Station (BTS). Main operation of RF Repeaters system is to receive low-power signal from BTS via radio frequency transmission and then transmit the amplified signal to the areas where network coverage is inadequate. And the mobile signal is also amplified and transmitted to the BTS via the opposite direction.
Wireless Wideband Repeater Features:
1.High linearity PA; High system gain;
2.Intelligent ALC technology;
3.Full duplex and high isolation from uplink to downlink;
4.Automatic Operation convenient operation;
5.Integrated technique with reliable performance;
6.Local and remote monitoring (optional) with automatic fault alarm &remote control;
7.Weatherproof design for all-weather installation;
Repeater Applications:
Outdoor: Airports, Tourism Regions, Golf Courses, Tunnels, Factories, Mining Districts, Villages etc.
Indoor: Hotels, Exhibition Centers, Basements, Shopping Malls, Offices, Packing Lots etc.
Repeater Technicial Specification:
Items |
Testing Condition |
3g/WCDMA2100MHz Specification |
|||
Uplink |
Downlink |
||||
Working Frequency(MHz) |
Nominal Frequency |
1920 – 1980MHz |
2110 - 2170MHz |
||
Gain(dB) |
Nominal Output Power-5dB |
95±2 |
|||
Output Power (dBm) |
GSM modulating signal |
33±2 |
40±2 |
||
ALC (dBm) |
Input Signal add 20dB |
Po≤±1 |
|||
Noise Figure (dB) |
Working in-band(Max. Gain) |
≤5 |
|||
Ripple in-band (dB) |
Nominal Output Power -5dB |
≤2.0 (3.84MHz) |
|||
Time Delay (us) |
Working in-band |
≤5 |
|||
EVM(%) |
Working in-band |
≤12.5 |
|||
PCDE (dB) |
Working in-band |
≤35 |
|||
ACLR(dBc) |
±5MHz |
Working in-band |
≥-45 |
||
±10MHz |
Working in-band |
≥-50 |
|||
Gain Adjustment Step (dB) |
Nominal Output Power -5dB |
1dB |
|||
Gain Adjustment Range(dB) |
Nominal Output Power -5dB |
≥30 |
|||
Gain Adjustable Linear(dB) |
10dB |
Nominal Output Power -5dB |
±1.0 |
||
20dB |
Nominal Output Power -5dB |
±1.0 |
|||
30dB |
Nominal Output Power -5dB |
±1.5 |
|||
Spurious Emission(dBm) |
9kHz-1GHz |
BW:30KHz |
≤-36 |
≤-36 |
|
1GHz-12.75GHz |
BW:30KHz |
≤-30 |
≤-30 |
||
VSWR |
BS/MS Port |
1.5 |
|||
Picture taken from Installation Area:
Packing:
Our factory:
