High Quality Tetra 380 400MHz Repeater BDA Fiber Optic Signal Amplifier
Introduction:
- Cable-Access FOR: to receive BTS signal via a direct coupler closed to the BTS (recommended)
-
Wireless-Access FOR: to receive BTS signal via a Donor Antenna (applicable when no fiber optic cable connecting to the BTS); can be sorted into 2 sub-categories: Band-Selective and Channel-Selective
High Quality Tetra 380 400MHz Repeater BDA Fiber Optic Signal Amplifier
High Quality Tetra 380 400MHz Repeater BDA Fiber Optic Signal Amplifier
High Quality Tetra 380 400MHz Repeater BDA Fiber Optic Signal Amplifier are cost effective solutions to cut the overall cost of signal coverage extension without the added need of implementing more BTS sites. They can be applied to much large areas including large public buildings, shopping malls, exhibition halls, parking lots, tunnels and rural areas.
Features
1,No more self-oscillation and easy to choose installation location
2,For Cable-Access type, pure BTS signal picked up by the Donor Unit will greatly reduce the signal noise
3,The Remote Unit can be installed out of the BTS coverage
4,A full 360-degree coverage can be achieved
5,No need to occupy frequency resource as the link frequency
Specification:
Type |
High Quality Tetra 380 400MHz Repeater BDA Fiber Optic Signal Amplifier |
||||
Frequency |
UL: 450-457.5MHz DL: 460-467.5MHz |
||||
Output Power |
33dBm |
37dBm |
40dBm |
43dBm |
|
Gain |
50-65dB |
||||
Gain Adjust Range |
≥30dB;1dB/step |
||||
AGC Range |
≥25dB |
||||
IMD3 |
≤-50dBc |
≤-45dBc |
|||
Noise Figure |
≤5dB |
||||
Ripple in Band |
≤3dB |
||||
Time Delay |
≤10μs |
||||
Spectrum mask |
Meet ETSI specification |
||||
Spurious Emission |
9KHz-1GHz:≤-36dBm/30KHz;1GHz-12.75GHz:≤-30dBm/30KHz |
||||
Port Impedance |
50Ω |
||||
VSWR |
≤1.5 |
||||
Monitoring Mode |
Local;Remote(Optional) |
||||
Power Supply |
AC220V(Normal); AC110V or DC48V or Solar Powered(Optional) |
||||
Weight |
21kgs |
21kgs |
26kgs |
32kgs |
|
Software |
Standard |
||||
Local Monitoring |
PC via USB Port |
||||
Remote Monitoring |
Via SMS or GPRS Modem |
||||
Controlled Parameters |
Gain, Frequency, Repeater ON/OFF, Alarm Enable, etc. |
||||
Monitoring Parameters |
Gain, Frequency, Repeater ON/OFF, Alarm Message. |
||||
Alarm Items |
Repeater Failure, DC Failure, ALC Alarm, PLL Failure |
||||
Payment & Delivery:
| Payment Terms | L/C, Western Union, Paypal |
|---|---|
| Minimum Order | 1 |
| Lead Time / Delivery Time | 10Day(s) |
| Sample Available | YES |
| Delivery Details | 10~15days after received advanced payment; |
| FOB Port | Shenzhen |
| Loading Info | We offer as many shipping options as possible, including DHL, UPS, TNT, Fedex and EMS |
| Packing Info | Strong cartons lined with safety foam; |
| Target Market(s) | Africa(except Middle East), Central & Southern Asia, Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Southeast Asia, Western & Southern Europe |
Terms of sale:
Guarantee:
All the Items have twice test before packaging
30 Days Customer Satisfaction
Return Policy:
If for any reasons you are not satisfied with the products within 30 days, please contact us and we will advise return detail and arrange a full refund. Buyer is responsible for return shipping costs.
Feedback Policy:
Please leave us a positive feedback if you satisfy with our total services as well as the products, We will provide the priority of the after-sales service.
Warranty:
Three Months Free Replacement
We design, develop, manufacture, market and service Signal Amplifiers systems for cell phone, with our innovative, dedicated and experienced team we can provide high quality products and solutions you want from your amplifier suppliers.
ISO9001:2008 Certificated Factory:
Our present manufacturing service:
1) GSM/CDMA/WCDMA/IDEN/DCS/PCS/LTE and other Repeater, including:
1. Single band Repeater
2. Dual Band Repeater
3. Tri band Repeater
4. Optic Fiber Repeater
5. Wide Band Repeater
6. Channel Selective Repeater
7. ICS Repeater
2)All kind of Repeater Accessories, including:
1.Antenna
2.Splitter
3.Connector
4.Cable
5.Functional Modules
Signal System |
Frequency Range |
Output Power |
GSM900MHz Repeater |
Uplink:890-915MHz Downlink:935-960MHz |
Indoor:15dBm, 17dBm, 20dBm,23dBm Outdoor:33dBm,37dBm,40dBm,43dBm |
DCS1800MHz Repeater |
Uplink:1710-1785MHz Downlink:1805-1880MHz |
Indoor:15dBm, 17dBm, 20dBm,23dBm Outdoor:33dBm,37dBm,40dBm,43dBm |
GSM850MHz Repeater |
Uplink:824-849MHz Downlink: 869-894MHz |
Indoor:15dBm, 17dBm, 20dBm,23dBm Outdoor:33dBm,37dBm,40dBm,43dBm |
CDMA450MHz Repeater |
Uplink:450-457.5MHz Downlink:460-467.5MHz |
Indoor:15dBm, 17dBm, 20dBm,23dBm Outdoor:33dBm,37dBm,40dBm,43dBm |
CDMA800MHz Repeater |
Uplink:824-849MHz Downlink:869-894MHz |
Indoor:15dBm, 17dBm, 20dBm,23dBm Outdoor:33dBm,37dBm,40dBm,43dBm |
PCS1900MHz Repeater |
Uplink:1880-1890MHz Downlink:1960-1970MHz |
Indoor:15dBm, 17dBm, 20dBm,23dBm Outdoor:33dBm,37dBm,40dBm,43dBm |
3G 850MHz Repeater |
Uplink: 824-849MHz Downlink:869-894MHz |
Indoor:15dBm, 17dBm, 20dBm,23dBm Outdoor:33dBm,37dBm,40dBm,43dBm |
UMTS2100MHz |
Uplink:1920-1980MHz Downlink:2110-2170MHz |
Indoor:15dBm, 17dBm, 20dBm,23dBm Outdoor:33dBm,37dBm,40dBm,43dBm |
GSM900/1800MHZ |
890-915MHz/935-960MHz |
Indoor:15dBm, 17dBm, 20dBm,23dBm Outdoor:33dBm,37dBm,40dBm,43dBm |
1710-1785MHz/1805-1880MHz |
|
