Home > Electrical & Electronics > Telecommunication & Broadcasting > Repeater > Cavity RF GSM900MHz Duplexer ,Passive Components for Gsm900 Cellular Repeater
Cavity RF GSM900MHz Duplexer ,Passive Components for Gsm900 Cellular Repeater
US$ 1 - 99
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
kingtone
Model Number:
KT-GSM-B
Payment & Shipping
Payment Methods:
Port of Shipment:
XIAMEN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
OEM RF Fiber Optic Transceiver 350MHz~470MHz GSM/TETRA/CDMA2000/WCDMA/TD-SCDMAUS$ 1 - 1,999MOQ: 1 Piece -
Cavity RF WCDMA Duplexer( Passive Components)US$ 1 - 99MOQ: 10 Pieces
-
OEM RF Fiber Optic Transceiver for GSM/TETRA/CDMA2000/WCDMA/TD-SCDMAUS$ 1 - 1,999MOQ: 1 Piece
-
824-849MHz 869-894MHz CDMA800 or Gsm 850 Mhz DuplexerUS$ 1 - 999MOQ: 10 Pieces
-
Cavity RF WCDMA 3G Duplexer Passive Components for 3G Cellular RepeaterUS$ 1 - 99MOQ: 10 Pieces
Place of Origin
Fujian, China
Brand Name
kingtone
Model Number
KT-GSM-B
Specifications
GSM900MHz Duplexer1.High Q cavity design
2. High Power Handling
3.Low passive IMD
Quick Details
- Place of Origin: Fujian, China (Mainland)
- Brand Name: KINGTONE
- Model Number: KT-GSM-B
- VSWR: 1.3 Min
- Ripple in Bang: 0.6dB p-p max
- Isolation: ≥90dB
- Coupling: 25dB±2dB
- Power Handling: 50W
Packaging & Delivery
| Packaging Details: | foam cover packing |
|---|---|
| Delivery Detail: | Within20 days against payment |
<:article id=richTextContainer>
Specifications
GSM900MHz Duplexer
1.High Q cavity design
2. High Power Handling
3.Low passive IMD
Detailed Product Specification Model |
KT-GSM-B |
memo |
|
Frequency |
885-909MHz |
930-954MHz |
Can design according customer specification |
Insertion Loss |
1.2dB typical 1.5dB max |
|
|
Ripple in Bang |
0.6dB p-p max |
|
|
VSWR |
1.3 Min |
|
|
Return Loss |
≥20dB at BWo±5MHz |
|
|
Isolation |
≥90dB |
|
|
Coupling |
25dB±2dB |
|
|
Power Handling |
50W |
|
|
Operating Temperature |
-30 to +55 degree |
|
|
Storage Temperature |
-55 to +85 degree |
|
|
Operating Humidity |
0 to 90%, relative |
|
|
Port Connectors |
SMA-Female |
|
|
Surface Color |
Black or Gray |
Can design according customer specification |
|
