Flux recycle system welding line equipment
Welding Flux Recycling Machine
Column And Boom Welding Manipulator With Flux Recovery System
FRS-X series of flux suspended conveyor recovery system is based on the welding machine of the production process requirements of the development of a new generation of Flux processing equipment.
Flux recovery machine, transportation flux in one operation to fly planes in the tail end of the beam, the beam is installed on the side of the stainless steel tube is connected to the front of the beam flux and small mouth suction hopper. Built-in high-performance products that filter materials produced by the dust filter components, air vents through which really makes no dust emissions, in order to create a good working environment and lay a solid foundation. Local reasonably compact, well-controlled operation can be controlled in recent, very convenient and effective delivery recovery, performance and stability control, run-time noise and dust emissions from non-essential. This series of Flux recovery system for a variety of products that can be operated in accordance with welding machines require matching process.
Model |
FRS-2X |
FRS-3X |
FRS-4X |
FRS-5X |
Operating voltage |
AC380V/220V |
|||
Electrical power |
2.2kw |
3kw |
4kw |
5.5kw |
Recovery |
≤6M |
≤8M |
≤12M |
≤16M |
Speed of recovery |
6-12Kg/min |
|||
Flux capacity |
80kg |
100kg |
150kg |
150kg |
Air pressure |
0.4-0.8Mpa |
|||
Transmission distance |
8-20m |
|||
