Help CenterTube Lifting Rotator / Screw Adjustable Conventional Welding Rotator
Related Products
-
Automatic Pipe Welding Manipulator For Tank Inside / Outside WeldingNegotiableMOQ: 1 Set -
Automatic Industrial Pipe Welding Rotator Adjust By Bolt Or ScrewNegotiableMOQ: 1 Set
-
Self Aligning Rotator / Pipe Weld Rotator With PU Roller For Boiler IndustryNegotiableMOQ: 1 Set
-
Automatic Self Aligning Rotator For Pressure Vessel WeldingNegotiableMOQ: 1 Set
-
Lifting Welding Positioner / Head And Tail Stock Elevating Welding PositionerNegotiableMOQ: 1 Set
1. Introduction
Pipe welding rotator (lifting welding turn roller) is specially designed and manufactured for purpose of meeting the requirements of enhancing productivity, increasing the extent of automatic, reducing welder’s working intensity and adapting to piping workshop prefabrication.
The welding head will be relatively fixed, while the piping spool piece revolving at a specific rate, and the high efficient and low cost shielded welding or SAW process is adopted, so it has the features of easy-operation, reliable-performance and wide-application field.
2. Application
Used to weld, polish and assemble the cylinder-shells, and to line the shells with rubber.
3. Specification
Model |
Pipe diameter |
Maximum loading |
Motor |
Wheel speed |
Column elevating |
Overall dimension |
PR0.5 |
50-350mm |
0.5ton |
0.37kw |
0.1-1m/min |
Manual |
1260*500*410mm |
PR1 |
50-426mm |
1ton |
0.55kw |
1260*500*410mm |
||
PR5 |
50-630mm |
5ton |
1.3kw |
Motorized |
1900*1500*700mm |
|
PR10 |
100-1000mm |
10ton |
1.6kw |
2240*1510*800mm |
4. Option
a. Polyurethane wheelor Rubber wheel or steel wheel
b. Anti-creep function
c. Hydraulic lifting for fit up pipe
d. Hydraulic tilting function
e. Automatic traveling or Manual traveling on the rail
f. Customization
5. Advantage
We can make all kinds of rollers according different customers different requests. Maximum loading capacity can reach to 2000tons, self-aligned or adjustable roller beds/ turning rolls.
