Steel Plate Butt Joint Long Seam Welding Machine , Automatic Flat Butt Welding Machine

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Business Type:

Manufacturer, Trading Company

Year Established:

2009

Factory Size:

3,000-5,000 square meters

Wuxi Friendship Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Steel Plate Longitudinal Joint Butt Welding Machine

Steel plate butt joint welding machine/mig welding machine

Flat steel plate Welding Machine/Automatic straight seam welding machine, thin-wall tank welding

Automatic Flat Butt Welding Machine/Tank Welding/Double Sides Butt Sealing Machine

Automatic Steel Plate Joint Welding Butt Machine

1. Specification

Name	Specification
Effective welding width	Customized
Effective welding thickness	Customized
Work-piece material	Carbon steel, Stainless steel
Welding method	MAG/ MIG
Welding seam tracking system	Option
Welding seam effect	One side welder two sides are sharped, the height of welding seam on the reverse side is less than 1.5mm, beveling in advance
Clamp method	Hydraulic cylinder clamp and press
Welding speed	50-500mm/min
Welder source	Miller or Lincoln
Molding groove material	Copper
Molding groove cooling method	Water cooling
Dry running speed	Step-less adjustable (0-4000mm/min)
Welding action adjust	Manual adjust
Welding gun cooling method	Water cooling
Voltage	AC380V 50HZ

2. Supply range

Name	Quantity
Main framework	1 Set
Welder source	1 Set
Cooling system	1 Set
Welding cart	1 Set
Centering and positioning device	3 Sets
Wire feeding device	1 Set
Work-piece conveyor	1 Set
Electric control system	1 Set

5. Main components

Name	Brand
Welding seam tracking system (Option)	ipod
Servo motor	Panasonic
Drag chain	Koduct
Welder	Miller
Relay	Omron
Connector	Schneider
Button	Schneider
PLC/ Touch screen	Delta
Control	Friendship Machinery
