PE multi-layer pipe extrusion
PE composite pipe making mahcine
PE co-extruder line
PE multi-layer pipe extrusion/single screw extruder
The extrusion line newly developed based on European technique and systemic study and research of new type pipe productionrep line, its suitable for PE,PP and other polyolefine pipes high-speed extrusion. The extrusion line has many advantages, such as , neat, outline, highly automatic control, stable performance, it's greatly repulted by the customers due to European performance and domestic price and it;s the best option as the subsititute of the imported one.
High-efficiency single screw extruder has standed size, all the equipments are controlled by the PLC/PCC smart modular, further , the automatic control, real-time data record and closed-loop control are realized, the advantages are high output, high adaptability for different raw material, highly stable good-quality extrusion and so on.
Model number |
PE-16/63 |
PE-20/110 |
PE-50/160 |
PE-75/250 |
PE-110/315 |
PE-200/450 |
PE-315/630 |
PE-400/800 |
Pipe diameter |
16-63mm |
20-110mm |
50-160mm |
75-250mm |
110-315mm |
200-450mm |
315-630mm |
400-800mm |
Max output |
150kg/h |
200kg/h |
350kg/h |
350kg/h |
350kg/h |
450kg/h |
850kg/h |
850kg/h |
Production rate |
1-15m/min |
1.2-12m/min |
0.6-8m/min |
0.5-4m/min |
0.4-3.7m/min |
0.3-3m/min |
0.2-2m/min |
0.1-1 m/min |
Extruder model |
SJ-65/30 |
SJ-65/33 |
SJ-75/33 |
SJ-75/33 |
SJ-75/33 |
SJ-90/33 |
SJ-120/33 |
SJ-120/33 |
Installed power |
85kw |
110kw |
125kw |
180kw |
260kw |
325kw |
480kw |
600kw |
Center height |
1000mm |
1000mm |
1000mm |
1000mm |
1100mm |
1100mm |
1200mm |
1300 |
Installation area |
35x3.0x2.0m |
38*3.1*2.2m |
38*3.1*2.2m |
40*3.2*2.4m |
42*3.2*2.4m |
52*3.3*2.6 m |
60*3.5*2.8m |
68*3.6*3.0m |
