Home > Industrial Equipment & Components > Fastener & Fitting > Gasket & Washer > Spiral Wound Gasket With Outer Ring

Spiral Wound Gasket With Outer Ring

Name: Spiral Wound Gasket With Outer Ring
Brand: hengda graphite
SKU: 122339667

Spiral Wound Gasket With Outer Ring thumbnail-1

Spiral Wound Gasket With Outer Ring photo-1

Negotiable MOQ: 200 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Hubei, China

Brand Name:

hengda graphite

Model Number:

HDG102

Contact Supplier Request Quote Chat Now

China Sciences Hengda Graphite Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or Ningbo port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hubei, China

Brand Name hengda graphite

Model Number HDG102

Material Graphite

Shape Ring Gasket

Standard or Nonstandard Standard

Specifications

Basic type graphite + metallic stripe
Outer ring type: CS, SS304,SS316
Inner ring type: SS304,SS316

Description

Spiral wound gasket is formed of V-shaped or W-shaped metallic stripe and non-metallic filler by means of lamination, spiral wounding and dot welding its beginning end by dot welding. Depend on its excellent compress resilience, it can sealing spot where the alteration of temperature and pressure is frequent. It can be used as the static sealing parts of pipe, valve, pump, thermal exchange, condensing power, plain hole and man hole of flange, etc. It has been widely applied in the fields of petrochemical, mechanical manufactory, power station, metallurgy, shipbuilding, medical and pharmaceutical nuclear powder station and navigation, etc.

Material selection

Materials of Metallic Stripe and Inner and Outer Rings		Fillers			General thickness(mm)
Name	Code	Name	Code	Applicable Temperature	V-shapped Gasket/Ring	W-shaped Gsket/Ring
Carbon steel	CS	Asbesttos	ASB	500	3.2/2.0 4.5/3.0 5.5/3.0	4.8/3.0 7.2/4.0
Stainless Steel	304(L),316(L)	Graphite	FG	650
		Tetrafluoro	PTFE	260
