HIGH QUALITY Led Tunnel Light

HIGH QUALITY Led Tunnel Light thumbnail-1
HIGH QUALITY Led Tunnel Light photo-1
US$ 200 - 500 MOQ: 100 Pieces
Key Specifications
Get Latest Price
LED Light Source:
CREE or Epistar
Input Voltage(V):
AC220V or AC110V
Lamp Power(W):
180
Contact Supplier Request Quote Chat Now
Guangdong Delos Lighting Industrial Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source CREE or Epistar
Input Voltage(V) AC220V or AC110V
Lamp Power(W) 180
Lamp Luminous Flux(lm) 16200
Lamp Luminous Efficiency(lm/w) 100
Color Temperature(CCT) Cool White
Working Temperature(℃) -30, 50
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum Alloy
IP Rating IP65
Certification CE, CQC
Warranty(Year) 3
Place of Origin Guangdong, China
Brand Name DELOS
Model Number DL0608

Specifications

1.LED tunnel light;
2.Independent gear box;
3.72w,108w,144w,180w available;
4.IP65 led tunnel light.

I Key features of led tunnel light DL0608 SERIES:

1) Simple and elegant appearance;

2) Seperate light source and power supply for easy installation and maintenance;

3) Design theory of 23° temperature raise;

4) Unique optical systerm conforming to tunnel lighting standarts;

5) Superior tempered glass diffuser ensure high ligh transmission and invariant color;

6) Long life power driver ensures above 50000 hours use-life and has short ,open-circuit and over-heat protection.



II Specification of led tunnel light DL0608 SERIES:

Item No. DL0608 DL0608A DL0608B DL0608C DL0608D DL0608E DL0608F DL0608G DL0608H DL0608I DL0608J DL0608K
Input Voltage AC85-265V AC85-265V AC85-265V AC85-265V AC85-265V AC85-265V AC85-265V AC85-265V AC85-265V AC85-265V AC85-265V AC85-265V
Frequency 47-63Hz 47-63Hz 47-63Hz 47-63Hz 47-63Hz 47-63Hz 47-63Hz 47-63Hz 47-63Hz 47-63Hz 47-63Hz 47-63Hz
Power Factor >0.95 >0.95 >0.95 >0.95 >0.95 >0.95 >0.95 >0.95 >0.95 >0.95 >0.95 >0.95
THD <15% <15% <15% <15% <15% <15% <15% <15% <15% <15% <15% <15%
Light Source CREE 72*1W CREE 108*1W CREE 144*1W CREE 180*1W CREE 48*1.5W CREE 72*1.5W CREE 96*1.5W CREE120*1.5W CREE 36*2W CREE 54*2W CREE 72*2W CREE 90*2W
Led Power 72W 108W 144W 180W 72W 108W 144W 180W 72W 108W 144W 180W
System Consumption 81W 122W 163W 203W 81W 122W 163W 203W 81W 122W 163W 203W
LED Luminous Efficiency >100lm/W >100lm/W >100lm/W >100lm/W >95lm/W >95lm/W >95lm/W >95lm/W >80lm/W >80lm/W >80lm/W >80lm/W
Initial Luminous Flux >7200lm >10800lm >14400lm >18000lm >6840lm >10260lm >13680lm >17100lm >5760lm >8640lm >11520lm >14400lm
Constant Luminous Flux >6480lm >9720lm >12960lm >16200lm >6156lm >9234lm >12312lm >15390lm >5184lm >7776lm >10386lm >12960lm
Luminaire Efficiency >80% >80% >80% >80% >80% >80% >80% >80% >80% >80% >80% >80%
System Rresistance 0.32°C/W 0.21°C/W 0.16°C/W 0.13°C/W 0.32°C/W 0.21°C/W 0.16°C/W 0.13°C/W 0.32°C/W 0.21°C/W 0.16°C/W 0.13°C/W
Dimension(mm) 360*349*79 495*349*79 630*349*79 765*349*79 360*349*79 495*349*79 630*349*79 765*349*79 360*349*79 495*349*79 630*349*79 765*349*79

HIGH QUALITY led tunnel light

HIGH QUALITY led tunnel light

HIGH QUALITY led tunnel light
