Electric slip ring manufacturer,wind power slip ring, wind turbine slip ring
- Smaller appearance, convenient installation
- Multichannel signal transmission, the anti-interference design
- Double gold rail contact design - long life
- Easy dial tdesign-Harting connector
- According to different environment,it's equipped with the temperature controller
- According to China's actual use environment, it is increased seal design,In this case, the product is free maintenance.
- Longer using time
wind power slip ring specification:
1.electrical parameter
| Electrical Data | |
| Channels | 5 |
| Rated Current | 20A/Channel,3Channels ;2A/Channel,2Channels |
| Rated Voltage | 240VAC/240VDC |
| Dielectric Strength | 500VAC@50Hz,60s |
| Insulation Resistance | 1000ΜΩ/500VDC |
| Electrical Noise | ≤0.01Ω |
| Lead Length | 250mm |
2.Mechanical parameter
| Electrical Data | |
| Operating Speed | 5 |
| Operating Temperature | 20A/Channel,3Channels ;2A/Channel,2Channels |
| Operating Humidity | 240VAC/240VDC |
| Contact Material | 500VAC@50Hz,60s |
| Structure Material | 1000ΜΩ/500VDC |
| IP Grade | ≤0.01Ω |
3.Typical application
uElectrical test equipment
uManufacturing and process control equipment
uIndexing tables, Cable reels
uRobotics, rotary sensors, urgent illumination equipment
uExhibit / display equipment
uCCTV pan
uLaboratory equipment
uAviation, military, marine and medical equipment
uWind generator
4.Benefits
uCompact for ease of incorporation in small mechanisms.
uOutstanding signal handling capability to transfer the most demanding communication protocols
5.Option
uOperation speed, current &voltage
uConnector
uNo. of circuits
uHousing material
uPosition of wire outlet
uProtection level (dust and water)
uPower ring with 5A and 10A is available upon 2A rings combination
uCompatible with digital signal and analog signal such as RS series signal, data bus protocols, Ethernet signal and so on.
Installation Guide
- Capsule slip ring is designed for being installed with flange on a sleeve bracket.
- Rotor must be concentric driven by a flexible link (such as plastic tube or screw tube). Rotor lead wire can do as this driver at limited-speed.
- As the photograph shows, screws with washer can be used to install slip ring, these washers can avoid flange too tight.
Attentions:
- Slip ring can not support the weight of equipment which connects with it, rotating equipment should be fastened so that its weight will no fall on the rotor.
- Slip ring should be used in dry, low dust environment. If used outdoor, shield is necessary.
- The surface of lead wire should avoid being damaged while equipment rotating, all lead wire can not bear weight while you put the lead wire in order.
- No damaging the surface of lead wire while barking its end.
Grand is located Hangzhou, the most beautiful city in China. Our plant covers an area of 3,000 square meters and has 148 employees. Grand specializes in a wide range of military and civilian slip rings which are positioning at medium and high-end market. Grand achieved the international certificates of ISO9001:2008, CE and RoHS, and we control quality strictly basis specified certification standard to ensure that our each product comes stable and good quality.
Certificate:
If you have any demand,please provide the specification as follows:
