Specifications
Granite grinding slab machine1.Good Flatness
2.Panel Uniformity
3.High Luminance
4.Widely used in China
Granite grinding slab machine
1.The machine possesses features full automatic operation, fast processing speed and easy handling.
2.It uses resin grinding disc,which is light,less-power consumed and high-polishing efficient.
3.The machine's power consumption is only 1/3 comparing with traditional continuous polishing machines.
4. Control system adopts PLC terminal control with LCD touch screen terminal for parameter setting and fault prompts.
5. Elevation of polishing head and pressure of grinding is controlled by air pressure and ajustable.
6. The machine is equipped with variable-frequency adjustable speed system for the grinding speed and the conveyor speed's adjustment.
7. The polishing process is all automatic,for the polishing heads are able to recognize the shape of slabs intelligently.
Specifications
| Product type | ZDM24C/0.9 | ZDM24C/1.2 |
| Number of grinding head | 24 | 24 |
| Power of main motor | 7.5kw | 7.5kw |
| Total power | 201.75kw | 201.75kw |
| Grinding head diameter | 200mm | 200mm |
| Grinding plate width | 900mm | 1200mm |
| Grinding plate depth | 10-50mm | 10-50mm |
| Beams swing speed | 3-35m/min | 3-35m/min |
| Speed into the boards | 1-3m/min | 1-3m/min |
| Cooling water pressure | 0.1-0.15Mpa | 0.1-0.15Mpa |
| Water consumption | 25m3/h | 27m3/h |
| Air supply pressure | 0.8Mpa | 0.8Mpa |
| Weight | 16t | 19t |
| Dimension(L×W×H) | 12800*2700*2300(mm) | 12800*2700*2300(mm) |
Pictures:
Granite slab auto polish machine is covered by thick plastic film,then reinforced by iron wire,shipping by 40fHQ container.
The machine is covering with thick plastic film.
Well-packed, the machine is sending to Thailand.
Other products package
You see, all products is covered with thick film before putting into the container.
1.Warranty(Non artificial damage): 6 months for spare parts;12 months for main parts.
2.If you requires we will send installation person for you to help install the machine and teach you how to operate it.
3.Special customized design is available.
XINGYI(CHINA)POLISHING MACHINE CO.,LTD.
Address1: NO.C2,Area 11,Anping Development Area,Quanzhou City,Fujian Province,china.
Address2: Kemu Industrial Area,Anhai Town,Jinjiang City,Fujian
Tel: +86-595-36792992
Web: www.xymachinery.en.china.cn
Factory
You are welcome to visit our factory!
Certificate
Company's phone numbe(scan the pic to get it!)
Company website
If you want more details or have any questions,we would appreciate for receiving your message.
Skype: xingyistone06
