Transistor
1)ISO9001 & CE
2)10 years professional technical
3)As manufacturer with high quality and low price.
Features |
|
1.High reliability 2.Low forward voltage drop 3.Space and weight saving 4.Max junction temperature up to 150°C 5.Isolated mounting base, 2500V~ 6.Simple mounting and easy maintenance |
Applications |
|
1.Inverter welder 2. power supplies(SMPS) 3.Battery DC power supplies 4.Field supply for DC motors 5.DC supply for PWM inverter 6.Electric drives and auxiliaries 8.Supplies for DC power equipment 9.specially designed for stamford series products. |
Module Circuit Diagram:
TYPE |
IT(AV) |
VRRM |
ITSM |
VTM |
IDRM |
VISO |
RTH |
IF(AV) |
VDRM |
45℃10ms |
VFM |
@Tc |
|||
A |
V |
A |
V |
mA |
V |
℃/W |
|
MXG(Q)* |
25 |
400-1800 |
350 |
≤1.3 |
≤2 |
2500 |
0.32 |
MXY(Q)* |
40 |
400-1800 |
530 |
≤1.3 |
≤2 |
2500 |
0.26 |
MXG(Ⅰ)* |
40 |
400-1800 |
530 |
≤1.3 |
≤2 |
2500 |
0.26 |
MXY(Ⅰ)* |
50 |
400-1800 |
650 |
≤1.3 |
≤2 |
2500 |
0.34 |
MXG(Ⅱ) |
40 |
400-1800 |
530 |
≤1.3 |
≤2 |
2500 |
0.26 |
MXY(Ⅱ) |
50 |
400-1800 |
650 |
≤1.3 |
≤2 |
2500 |
0.3 |
MXG(Ⅲ) |
25 |
400-1800 |
350 |
≤1.3 |
≤2 |
2500 |
0.32 |
MXY(Ⅲ) |
40 |
400-1800 |
530 |
≤1.3 |
≤2 |
2500 |
0.26 |
MXGIV) |
50 |
400-1800 |
650 |
≤1.3 |
≤2 |
2500 |
0.3 |
MXY(IV) |
70 |
400-1800 |
900 |
≤1.3 |
≤3 |
2500 |
0.26 |
MXG(V) |
50 |
400-1800 |
650 |
≤1.3 |
≤2 |
2500 |
0.28 |
70 |
400-1800 |
900 |
≤1.3 |
≤3 |
2500 |
0.24 |
|
100 |
400-1800 |
1300 |
≤1.3 |
≤3 |
2500 |
0.19 |
|
MXG(VI) |
40 |
400-1800 |
530 |
≤1.3 |
≤2 |
- |
0.2 |
MXY(VI) |
50 |
400-1800 |
650 |
≤1.3 |
≤2 |
0.29 |
|
MXG(VII) |
50 |
400-1800 |
650 |
≤1.3 |
≤2 |
- |
0.21 |
MXY(VII) |
70 |
400-1800 |
900 |
≤1.3 |
≤3 |
0.19 |
