Good Price Generator Rectification Bridge
- 2000 Piece / Pieces per Month
- Shanghai
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | Anguang | Model Number: | MXY(Q)* |
Type: | Other, Bridge Rectifier, Generator Rectification Bridge | Application: | Generator | Package Type: | Surface Mount |
Peak Repetitive Reverse Voltage: | 400V-1800V | Mean On-State Current: | 25A-70A |
Packaging Details
Depending on the product size, but all ship with standard, secure packaging or customized for Generator Rectification Bridge
Product Description
Generator Rectification Bridge
1)ISO9001 & CE
2)10 years professional technical
3)As manufacturer with high quality and low price.
Features |
1.High Reliability 2.Low forward voltage drop 3.Space and weight saving 4.Withstand voltage AC 2500v 5.Max junction temperature up to 150°C 6.Simple mounting and easy maintenance |
Applications |
Generator Excitation Specially Designed For Stamford Series Products. |
Generator Rectification Bridge Circuit Diagram:
Generator Rectification Bridge
TYPE | IT(AV) | VRRM | ITSM | VTM | IDRM | VISO | RTH |
IF(AV) | VDRM | 45℃10ms | VFM | @Tc | |||
A | V | A | V | mA | V | ℃/W | |
MXG(Q)* | 25 | 400-1800 | 350 | ≤1.3 | ≤2 | 2500 | 0.32 |
MXY(Q)* | 40 | 400-1800 | 530 | ≤1.3 | ≤2 | 2500 | 0.26 |
MXG(Ⅰ)* | 40 | 400-1800 | 530 | ≤1.3 | ≤2 | 2500 | 0.26 |
MXY(Ⅰ)* | 50 | 400-1800 | 650 | ≤1.3 | ≤2 | 2500 | 0.34 |
MXG(Ⅱ) | 40 | 400-1800 | 530 | ≤1.3 | ≤2 | 2500 | 0.26 |
MXY(Ⅱ) | 50 | 400-1800 | 650 | ≤1.3 | ≤2 | 2500 | 0.3 |
MXG(Ⅲ) | 25 | 400-1800 | 350 | ≤1.3 | ≤2 | 2500 | 0.32 |
MXY(Ⅲ) | 40 | 400-1800 | 530 | ≤1.3 | ≤2 | 2500 | 0.26 |
MXGIV) | 50 | 400-1800 | 650 | ≤1.3 | ≤2 | 2500 | 0.3 |
MXY(IV) | 70 | 400-1800 | 900 | ≤1.3 | ≤3 | 2500 | 0.26 |
MXG(V) | 50 | 400-1800 | 650 | ≤1.3 | ≤2 | 2500 | 0.28 |
70 | 400-1800 | 900 | ≤1.3 | ≤3 | 2500 | 0.24 | |
100 | 400-1800 | 1300 | ≤1.3 | ≤3 | 2500 | 0.19 | |
MXG(VI) | 40 | 400-1800 | 530 | ≤1.3 | ≤2 | - | 0.2 |
MXY(VI) | 50 | 400-1800 | 650 | ≤1.3 | ≤2 | 0.29 | |
MXG(VII) | 50 | 400-1800 | 650 | ≤1.3 | ≤2 | - | 0.21 |
MXY(VII) | 70 | 400-1800 | 900 | ≤1.3 | ≤3 | 0.19 |
Company Profile
Established in 2007, we,Changzhou Anguang Electrical Appliance Co., Ltd. are a manufacturer specialized in production of electrical Insulating components,Power Modules and Terminal Blocks with faultless R & D, active sales and perfect after-sales.
We introduced high-tech equipment facilities like vacuum brazing furnace,automatic filling and sealing machines,laser marking to ensure fine quality of our products to meet your different requirements.
Our products are mainly used in the field of welders,generators, UPS,Industrial heating control,AC & DC motor control and Various rectifying power supplying.
With honesty, sincerity,strong technology and good after-sales,we 'll contribute ourselves to your busniess and establish long term mutual banefit with you! Welcome to contact.
