ISO Air Compact Cylinder DNC Series ISO6431
Detailed Product Description
Standard Pneumatic Cylinder
Standard Air Cylinder
* DNC Series ISO6431 /VDMA 24562 ( FESTO TYPE )
ISO15552
* Conform to ISO6431 and VDMA 24562 standard pneumatic cylinder;
* DNC Series are with similar FESTO DNC appearance, with slot on the cylinder barrel and end covers for magnet sensor mounting more conveniently;
* DNC series are with FESTO style and cover and mickey mouse barrel to be cost effective;
* Adjustable cushion on both cylinder end covers to make sure the cylinder works very smoothly safely and with low noise;.
* With self-lubricating bearing,the piston rod is lubrication free.
* Magnet and sufficient Fixing styles are available.
| Inner diameter(mm) | 32 | 40 | 50 | 63 | 80 | 100 | 125 |
| Motion Pattern | Double Action Type | ||||||
| Working medium | Air | ||||||
| Fixed type | Basic type, FA type, Fb type,CA type,CB type,CR type, LB type,TC type,TC-M type | ||||||
| Working pressure | 0.1~0.9MPa | ||||||
| Ensured Pressure Range | 1.35MPa | ||||||
| Operating Temperature | -5~70 degree centigrade | ||||||
| Operating Speed Range | 50~800 mm/s | ||||||
| Buffer type | Adjustable Buffer | ||||||
| Buffer Stroke | 24 | 32 | |||||
| Joint pipe bore | PT1/8" | PT1/4" | PT3/8" | PT1/2" | |||
PLS contact us for more detailed information.
