Small Milling Machine Price With 3 Axis Servo Motor Driven and Automatic Feeding

Name: Small Milling Machine Price With 3 Axis Servo Motor Driven and Automatic Feeding
Brand: TZHISING
SKU: 122086525

US$ 6,500 - 8,500 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

TZHISING

Tengzhou Hising Machine Tools Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO PORT SHANGHAI PORT

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name TZHISING

Model Number XL5032C

Type Vertical

CNC or Not Normal

Voltage 380V/415V/220V

Power(W) 5.5KW

Dimension(L*W*H) 2245X2100X2150MM

Weight 2850KG

Certification ISO9001, CE

Warranty 12 MONTHS

After-sales Service Provided Engineers available to service machinery overseas

MAIN FEATURES OF small milling machine price with 3 axis servo motor driven and automatic feeding:

1. CAST IRON OF HIGH RIGIDITY.

2. GUIDEWAYS QUENCHED AND FINE GRINDED.

3. DIFFERENT VOLTAGES REQUESTS ACCEPTABLE.

4. DIFFERENT COLORS REQUESTS ACCEPTABLE.

5. OEM SERVICE PROVIDED

6. 3 AXIS AUTOMATIC FEEDING DRIVEN BY SERVO MOTOR

MAIN SPECIFICATION OF small milling machine price with 3 axis servo motor driven and automatic feeding :

Specification	Unit	XL5032	XL5032C	XL5032CL
Table size	mm	1325X320		1600X320
T-slots(NO./Width/Pitch)		3/18/70
Longitudinal travel	mm	750	1100	1300
Cross travel	mm	320
Vertical travel	mm	460	450
Table feed (X/Y/Z)	mm/min	30-750/20-500/15-375 8steps
Table rapid speed(X/Y/Z)	mm/min	1200/800/600
Spindle taper		7:24 ISO50
Spindle speed range	r.p.m	50-1475
Spindle speed step	steps	12steps
Spindle travel	mm	70
Max. swivel angle of vertical milling head		±30°
Distance between spindle nose and table surface	mm	50-510	50-500
Distance between spindle axis and column guideway	mm	378
Torque of X/Y/Z axis AC servo motor	N.m	10
Main motor Power	kw	5.5
Overall dimensions (L×W×H)	mm	1800×2100×2150	2245×2100×2150	2520×2100×2150
Net weight	kg	2750	2850	2900
