Top Quailty Universal Radial Milling Machine From China

Name: Top Quailty Universal Radial Milling Machine From China
Brand: TZHISING
SKU: 122085975

US$ 1 - 9,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

TZHISING

Tengzhou Hising Machine Tools Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name TZHISING

Model Number X6332B/X6332C

Type Universal

CNC or Not Normal

Voltage Customer Requirement

Power(W) 3.7/2.2KW

Dimension(L*W*H) 1700X1520X2260MM

Weight 1500KG

Certification ISO9001:2008

Warranty 12 Months

After-sales Service Provided Engineers available to service machinery overseas

top quailty Universal Radial Milling Machine from China:

Specification of the Universal Radial Milling Machine(X6332B/X6332C):

SPECIFICATION	Unit	X6332B	X6332C
Spindle nose taper		7:24 ISO40	7:24 ISO40
Spindle travel	mm	150(vertical)	150(vertical)
Sleeve feed	mm/r	0.04/0.08/0.15(3 steps)	0.04/0.08/0.15(3 steps)
Distance from spindle to column	mm	200-550(vertical)	200-550(vertical)
Distance from spindle to table	mm	150-455(vertical)	150-500(vertical)
Distance from spindle center to table surface	mm	0-300(horizontal)	0-350(horizontal)
Distance from spindle center to arm	mm	190 (horizontal)	190 (horizontal)
Spindle speed range	r/min	(16 steps)66-4540(vertical) (12steps)60-1350(horizontal)	(16steps)63-5817(vertical) (12steps)60-1350(horizontal)
Worktable size	mm	1250×320	1250×320
Worktable travel(X/Y/Z)	mm	800×300×350	600×300×350
Worktable longitudinal/cross power feed	mm/min	22-555(8steps) 810(max.)	15-370(8steps) 540(max.)
Worktable elevating power feed	mm/min	560	560
T-slot No./width/distance of table	mm	3/14/70	3/14/70
Main motor	kw	3.7(vertical) 2.2(horizontal)	3.7(vertical) 2.2(horizontal)
Motor for rapid device of table	w	750	750
Motor of lifted table	w	750	1100
Speed of cooing pumps	L/min	12	12
N.W./G.W.	kg	1500/1700	1770/1900
Overall dimension	mm	1700×1520×2260	1720×1520×2225
