Universal Dividing Head BS-2

Universal Dividing Head BS-2 thumbnail-1
Universal Dividing Head BS-2 thumbnail-2
Universal Dividing Head BS-2 photo-1
Universal Dividing Head BS-2 photo-2
US$ 500 - 900 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
TZHISING
Model Number:
BS-2
Contact Supplier Request Quote Chat Now
Tengzhou Hising Machine Tools Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name TZHISING
Model Number BS-2
Application Milling
Drive Motor

 Universal Index B&Type

No.2(Head-stock)                                                                                Unit :mm/inches

Model

A

B

H

h

a

b

g

Taper of ceter

Diameter of spindle hole

LBS-2

370

14.56

280

11.02

236

9.29

133

5.24

212

8.35

134

5.27

16

0.63

B&S No.10

25.4

1

ACCURACY                              MAXIMUM

                                                   VARIATION



Center concentricity                              .0.006″

                                                                  .015mm



Inside taper concentricity of dividing spindle

(1)    Measured at spindle nose                 (1).0004″      .01mm

(2)    Measured at arbor(8″long)               (2).0012″      .03mm



Axial movment of dividing spindle                .0004″

                                            .01mm



Alignment of dividing head and tailstock

(1)Vertical plane                           (1).0008″      .02mm

(2)Horizontal plane                        (1).0008″      .02mm



Dividing Accuracy of Worm Drive

Maximum Cumulative spacing error                  1′30″



No.2 Tail-stock                                            Unit:mm/inches

Model

A1

B1

H1

h

a1

b1

g1

LBS-2

183

7.20

87

3.42

156

6.14

133

5.24

175

6.89

122

4.80

16

0.63

Model

Gross Weight

Meas CFT

Applicable Chuck

LBS-0

21 kgs

47 lbs

0.8

4″ or 5″

LBS-1

30 kgs

66 lbs

1.3

5″ or 6″

LBS-2

73 kgs

161 lbs

3.5

6″ 7″ or 8″

Universal dividing head BS-2Universal dividing head BS-2

Universal dividing head BS-2
