2015 Newest 28 inch mountain electric bike with EZ15194 TDB28S003

FOB Price

Negotiable / Piece

104 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Wattage	251 - 350w	Voltage	36V
Power Supply	Lithium Battery	Wheel Size	Other, 28”
Motor	Other, Brushless, with waterproof plug	Certification	Other, EN15194
Frame Material	Aluminum Alloy	Foldable	No
Max Speed	Other, >25KM/H
Place of Origin	China	Brand Name	ENDA
Model Number	TDB28S003

2015 Newest 28 inch moutain electric bike	TDB28S003
Performance
Max Speed:	25 km/h
Range:	>40 kms
Climbing Degree:	≤8 degrees
Run Mode:	Pedalling Assist Mode
Recharging Time:	6-8 hours
Charge Cycle Times:	>500 times
Load Capacity:	100 kgs

Electric Assist System
Sensor:	LiShui, 1:1intelligent Speed Sensor
Display:	Kingmeter, KM5S-LCD, with waterproof plug
Motor:	8-Fun,Front,250 Watt, Brushless,with waterproof plug
Controller:	LiShui,36V/250W, EN-15194 approval
Battery:	Lithium 36V/11 Ah, with Intelligent Protection System and anti-theft lock, USB connection
Charger:	Li-ion battery charger, GS approval

Features
Frame:	700C L type E-bike, inter-8 speeds, Aluminium frame, TIG welded W/battery bracket and Pivots
Fork:	Suntour, Aluminium, 700C Susp fork, for V brake, w/Pivot, with buckle and spring
Handlepost:	Aluminium, Rising crescent, Silver
Drive system:	Shimano, Right side, Grip shift for inter-8 speeds
Brake:	F: Tektro, V brake R: Shimano Roller brake
N.W:	26 kgs

Main Parts Feature:
