floor stand server cabinet 42U
- 10000 Set / Sets per Month
- shenzhen
- T/T L/C D/P D/A Credit Card
- 30A automatic transfer switch
- Hot selling rack cabinet weatherproof/SK-235M waterproof telecom outdoor cabinets with fan
- Hot selling rack cabinet weatherproof/SK-291 outdoor telecom cabinet rack
- Hot selling rack cabinet weatherproof/SK-345 outdoor waterproof cabinet
- Hot selling rack cabinet weatherproof/ SK-400B fan type ip54 battery cabinet
- Hot selling rack cabinet weatherproof/SK-235M waterproof outdoor racks with fan
Product Details
Place of Origin: | Guangdong, China | Brand Name: | KTMP | Model Number: | KTMP-SF-27 |
Protection Level: | IP65 | Type: | Distribution Box | External Size: | Optional |
Product Description
floor stand server cabinet 42U
Model: KTMP-SF-27
Specification :
Model | 600*800mm |
Capacity | 42U |
standard | Comply with ANS/EIA RS-310-D,IEC297-2,DIN4149,PART1,DIN41491 Standard; |
IP grade | IP20 |
Color | RAL9004, RAL9005, RAL7035 etc |
Thickness: | mounting profile: 2.0mm,mounting angle:1.5mm others: 1.2mm |
Material: | Nine-folded profiled(SPCC) |
Static Loading Capacity: | 1000Kgs |
Packing | assembled: plastic bag, then covering corrugated case,wooden case for optional |
Surface finish: | Degreasing, Pickling, Phosphating, Powder coated |
Door | high vented front door and dual real panels |
Features :
1. 19" standard installation with adjustable dimension, Elegant design with precision measurement and craftsmanship;
2. High-density vented front door & rear door enable IT equipment for protection and ventilation, with turning angle above 120 degrees and ventilation rate above 55%;
3. Side panels with locks on both side for protection and assembly.
4 Various optional accessories and bottom seat for stable stand for choice;
5.Customization requests welcome.
Details Show :
Main Parts :
No. | Name | QTY | Material | Remarks | |
600w | 800w | ||||
1 | Frame | 1 | 1 | SPCCT=1.5 | 9 folds profiled bracket |
2 | Front door | 1 | 1 | SPCCT=1.2 | Flat door with vented holes , optional |
3 | Front door lock | 1 | 1 | —— | MS831/optional |
4 | Left rear door | 1 | 1 | SPCCT=1.2 | Flat door with vented holes , optional |
5 | Rear door lock | 1 | 1 | —— | M818/optional |
6 | Right rear door | 1 | 1 | SPCCT=1.2 | Flat door with vented holes , optional |
7 | Top cover | 1 | 1 | SPCCT=1.2 | Fan tray is available |
8 | Side Panel | 2 | 2 | SPCCT=1.2 |
|
9 | Castor setup panel | 2 | 2 | SPCCT=2.0 |
|
10 | Castor | 4 | 4 | —— |
|
11 | Support feet | 4 | 4 | —— | M12 |
12 | Mounting beam | 4/2 | 12/8 | SPCCT=1.5 | Below 27U(include 27U):2pcs, 800w cabinet:12pcs |
13 | Mounting profile | 4 | 4 | SPCCT=2.0 |
|
14 | Spacer | no | 12/8 | SPCCT=2.0 | Only for 800W cabinet / Below 27U(include 27U):8pcs |
15 | Cable management holder with cover | no | 2 | SPCCT=1.2 | Only for 800W cabinets |
16 | Bottom panel | 1 | 1 | —— | Optional accessories |
Width: 600mm/800mm;
Depth: 600/800/900/960/1000/1100/1200mm
Height: 22/27/32/35/37/42/45/47U
Remark: we mainly produce the customized sheet metal parts, all the products display here are to show our business scope only. Thanks!
Advantage :
1.Secure,firm and reliable
2. Easy to maintain equipment
3. Two Packing Ways:
1).Assembly packing to save labour cost, ready to resell or use
2).Disassembly packing to save space and transport cost, easy to assemble
4.Certification: ISO 9001:2000
5. OEM/ODM service available
Other Series :
Company Introduction :
Shenzhen KTMP Technology Company Limited is a professional sheet metal products
manufacturer . As a skilled manufacturer in sheet metal processing industry for 12 years , KTMP is a
company with the whole line of designing , producing , selling and trading a standard series of
products while continually making strides in new product development . Welcome to OEM all kinds of
network/ server cabinets .
Certification :
FAQ :
Your satisfaction is our greatest feedback.
Q:If OEM available?
A:Yes, we provide all of our products OEM.
Q:What are your company normal payment?
A:We accept L/C; T/T; D/P; D/A; Western Union;
Q: What are your company normal export terms?
A:We normally export with DHL EMS FedEX UPS and so on.
Q:Is sample available?
A:Sample is available.
