42U gray color server cabinet
Model: KTMP-SF-4
Specifications:
Model | 600 x 800 42U |
Capacity | 42U |
Standard | Comply with ANSI/EIA, RS-310-D, IEC297-2, DIN41491; PART1, DIN41494; PART7, GB/T3047.2-92 standard, compatible with 19 inch international standard, metric system and ETSI standard. |
IP grade | IP20 |
Color | RAL 9004 (Black) or RAL 7035(Gray) |
Thickness: | Mounting profile: 2.0mm, others: 1.2mm to 1.5mm |
Material: | High quality SPCC (cold rolled steel) |
Static Loading Capacity: | 1000Kgs |
Packing | assembled: plastic bag, then covering corrugated case,wooden case for optional |
Surface finish: | Degreasing, Pickling, Phosphating, Cleaning, Drying, Powder coating |
Door | Mesh door |
Features :
1. Comply with ANSI/EIA, RS-310-D, IEC297-2, DIN41491; PART1, DIN41494; PART7, GB/T3047.2-92 standard, compatible with 19 inch international standard, metric system and ETSI standard.
2. The frame is made of nine folds profile and welded by special 3-Tees .The whole structure is stable and the static loading is 1000Kgs
3. Excellent ventilation & heat dissipation. High density perforated single front door & double open steel rear doors make the vented area no less than 70% of the door area. The front door is optional.
4. Side panels adopt quick open latches designing, which makes the disassembly & assembly process conveniently.
5. Support feet (M12) and castors can be installed at the bottom simultaneously, ensuring convenient movement and stable placement.
6. Door hinges are interchangeable; cable entries on top panel are equipped with rubber covers. Fan unit is optional for active cooling solution.
7. The inner installation depth is adjustable (take 25MM as unit); the height of the capacity is adjustable (take 1U as unit).
8. Customizations based on customer requirements are welcomed; various kinds of specifications and structure adjustment are available.
Picturer Show :
Main parts :
No. | Name | QTY | Material | Remarks | |
600w | 800w | ||||
1 | frame | 1 | 1 | SPCCT=1.5 | 9 folds profiled bracket |
2 | Front door | 1 | 1 | SPCCT=1.2 | Arch door (with vented holes) |
3 | Lock Ms3011 | 1 | 1 | —— | MS3011 |
4 | Left rear door | 1 | 1 | SPCCT=1.2 | Vented holes |
5 | Right rear door | 1 | 1 | SPCCT=1.2 | Vented holes |
6 | Lock Ms3012 | 1 | 1 | —— | MS3012 |
7 | Strip | 1 | 1 | SPCCT=1.5 |
|
8 | Rear door under panel |
|
| SPCCT=1.2 |
|
9 | Side door | 2 | 2 | SPCCT=1.2 | Latch for side door |
10 | Top cover | 1 | 1 | SPCCT=1.2 | Two entry holes |
11 | Castor tray | 4 | 4 | SPCCT=2.5 |
|
12 | Caster | 4 | 4 | —— | 2.5 without brake |
13 | Adjustable feet | 4 | 4 |
|
|
14 | Mounting angle | 2 | 2 | SPCCT=1.5 |
|
15 | 19 inch bar | 4 | 4 | SPCCT=2.0 |
|
16 | Cable slot | —— | 2 | SPCCT=1.2 | Only for 800w |
17 | Bottom panel |
|
| SPCCT=1.2 | Optional accessories |
Advantage :
1. Rich experience on manufacture sheet metal industry
2. High quality material , exquisite design in every details
3. Secure , firm and reliable , Easy to maintain equipment
4. Two packing ways :
(1) Assembly packing to save labour cost , ready to resell or use
(2) Disassembly packing to save space and transport cost , easy to assemble
5. OEM/ODM service available
Other Seriers
Company Introduction :
Shenzhen KTMP Technology Company Limited is a professional sheet metal products
manufacturer . As a skilled manufacturer in sheet metal processing industry for 12 years , KTMP is a
company with the whole line of designing , producing , selling and trading a standard series of
products while continually making strides in new product development . Welcome to OEM all kinds of
network/ server cabinets .
Certifications:
FAQ:
Your satisfaction is our greatest feedback.
Q:If OEM available?
A:Yes, we provide all of our products OEM.
Q:What are your company normal payment?
A:We accept L/C; T/T; D/P; D/A; Western Union;
Q: What are your company normal export terms?
A:We normally export with DHL EMS FedEX UPS and so on.
Q:Is sample available?
A:Sample is available.
