Exquisite server enclosure for sale
Model: KTMP-SF-6
Specification :
Model |
600*800*2000mm |
Capacity |
42U |
Standard |
Comply with ANS/EIA RS-310-D,IEC297-2,DIN4149,PART1,DIN41491 Standard; |
IP grade |
IP20 |
color |
RAL9004, RAL9005, RAL7035 etc |
Thickness: |
Mounting profile: 2.0mm,mounting angle:1.5mm others: 1.2mm |
Material: |
Nine-folded profiled(SPCC) |
Static Loading Capacity: |
1000Kgs |
Packing |
assembled: plastic bag, then covering corrugated case, wooden case for optional |
Surface finish: |
Degreasing, Pickling, Phosphating, Powder coated |
Door |
Perforated front door |
Features :
1.Exquisite design with precise craftsmanship;
2.Nine-folded profiled,welded frame with high intensity;
3.High-density perforated front door (single open)with oer 180 turning degree:
4.High-density perforated rear door(dual open)enable equipment ventilation and reliable operation with ventilation rate above 50%;
5.Removable side panel, easy to install and maintain with moon shaped lock;
6.Connected by four-corner to ensure the strength and stability;
7.Adjustable feet and castors are available;
8.Adjustable cable entry on the top, bottom with cable entrance;
9.Advanced moon-shaped locks;
10.Metal cable ring on the mounting profile for cable management
11.Efficient baying kit of cabinet, earthing kit;
12.Supplied as welded structure, also supplied as a flat packing,
13.Various optional Accessories for common using;
Details Show :
Optional Lock :
Main Component :
No. |
Component |
quantity |
unit |
material specification |
Surface |
1 |
Top cover |
1 |
pc |
SPCC cold rolled steel T1.2 |
Powder coated |
2 |
Fan unit |
1 |
set |
SPCC cold rolled steel T1.2 |
Powder coated |
3 |
Frame |
2 |
pc |
Nine-folded Profiled |
Powder coated |
4 |
Supporting Tray |
4 |
pc |
SPCC cold rolled steel T2.0 |
Powder coated |
5 |
Mounting profile |
4 |
pc |
SPCC cold rolled steel T1.5 |
Powder coated |
6 |
Mounting angle |
6 |
pc |
SPCC cold rolled steel T2.0 |
Powder coated |
7 |
Side panel |
2 |
pc |
SPCC cold rolled steel T1.2 |
Powder coated |
8 |
Perforated front door |
1 |
pc |
SPCC cold rolled steel T1.2 |
Powder coated |
9 |
Perforated rear door |
1 |
pc |
SPCC cold rolled steel T1.2 |
Powder coated |
10 |
Advance moon shaped lock |
6 |
pc |
--- |
Galvanization |
11 |
Castor |
4 |
pc |
--- |
--- |
12 |
M10 adjustable feet |
4 |
pc |
--- |
--- |
13 |
M6 B-head screw and M6 square nut |
20 |
pc |
steel |
Color zinc coated |
14 |
Allen wrench |
1 |
pc |
steel |
Black |
15 |
Metal cable ring |
6 |
pc |
steel |
Power coated |
16 |
Spacer(only for 800mm width) |
12 |
pc |
SPCC cold rolled steel T1.2 |
Power coated |
17 |
Vertical cable manager (800mm width) |
2 |
pc |
SPCC cold rolled steel T0.8 |
power coated |
Advantage :
1.Secure,firm and reliable
2. Easy to maintain equipment
3. Two Packing Ways:
1).Assembly packing to save labour cost, ready to resell or use
2).Disassembly packing to save space and transport cost, easy to assemble
4.Certification: ISO 9001:2000
5. OEM/ODM service available
Other Series :
Company Introduction :
Shenzhen KTMP Technology Company Limited is a professional sheet metal products
manufacturer . As a skilled manufacturer in sheet metal processing industry for 12 years , KTMP is a
company with the whole line of designing , producing , selling and trading a standard series of
products while continually making strides in new product development . Welcome to OEM all kinds of
network/ server cabinets .
Certification :
FAQ :
Your satisfaction is our greatest feedback.
Q:If OEM available?
A:Yes, we provide all of our products OEM.
Q:What are your company normal payment?
A:We accept L/C; T/T; D/P; D/A; Western Union;
Q: What are your company normal export terms?
A:We normally export with DHL EMS FedEX UPS and so on.
Q:Is sample available?
A:Sample is available.
