Specifications
1.quick start&small invest2.safe and pro-environment
3.save 20% fuel
Advanced technology coal gasification generator/ coal gasifier
What is double coal gasifier / furnance?
The double coal gasifier are divided into two parts: up coal gas and down coal gas.up coal gas go into electrical tar precipitator, heavy tar and dust are removed.the temperature of coal gas become 90-150 degree, then after through indirect air cooler , the temperature become 35-45 degree.Down coal gas go into cyclone dust collector,the temperature become 450-550 degree,after through indirect air cooler, the temperature become 35-45 degree. Then the up coal gas together with down coal gas go into the electric light oil tarps for further tar and dust reomved.The clean and cold coal gas are send to destination by pressure machine
Working principle of coal gasifier:
The coal granularity in 20-80mm is the ideal fuel. The small granules are in the stove, increasing the stove’s intensity of gasification, quickening reaction speed, improving the gasification efficiency of coal, to reach a state of complete gasification, make coal gas continuously and stably
Application of coal gasifier:
It is widely used in coal-fired, fuel boilers, kiln, metallurgy, chemical industry, aluminum, refractory materials, glass products and other products which need heat source equipment.
It is very ideal for the usage of boiler reconstruction.
1.Waterproof packing with the international export standard by 20ft, 40ft, 40hp container.
2. Equipment Fittings, Electric Motor and Power Cabinet will be packed in Wooden Case or Iron Box. Other Equipment will be packed by Color-Stripes Plastic Cloth.
3. Or as per customer's requirements.
Zhengzhou Sinoder Indutech Machinery Co., ltd (hereafter referred to as "Sinoder") is a joint-stock machinery manufacturing enterprise, integrating industrial scientific research, production and marketing. The company is located in the Industry Area Zone of Zhengzhou, China.
The main products cover industrial drying machines,industrial crushing machines, mineral processing machines, brick machines, biomass energetic machines, environment protection equipment, food oil press machines and other mechanical equipment. Our key product include stone crusher,sand maker, stone washing machine, ball mill, flotation cell, AAC block plant, rotaty drying machines, biomass burner, coal gasifier, oil press machine, packaging machine, breeding machines, fertilizer and pellets machine and other machines.
Sinoder offer not only products with good quality and competitive price, but also top service and solution.
Website:
1.Pre-sale services:
1) Selecting equipment type;
2) Designing and fabricating the products in accordance with the special requirements of the clients;
3) Training technical personnel for our clients;
2.Services provided during the sale:
Respect our clients; present the clients with ease, relaxation and a surprise; devote ourselves to improve the total value of our clients.
3. After-sale services:
Improve the added value of our products, and let the clients free from the using troubles:
1) Assisting the clients preparing for the first construction scheme;
2) Installing and testing the equipments;
3) Training the first-line operators on site;
4) Examining the equipment regularly;
If you want to know more information , Pls to contact us
Tel: 0371 55933391 Fax: 0371 55919082
