T097 compression load cell sensor,compression load cell ,load cell with good quality
Advantage of compression load cell : Model: T097
1. Compensation regulation using multiturn potentiometer with high stability
2.Water and dust proof housing,designed to fit environmental conditions of industrial applications
3.Prevent signal lightning and surge damage to the sensor
4.Trimming of signal,IP65 protection
5.Used to combine 4 signals to one output
Model : T097
Technical parameter : T097 compression load cell
Specifications |
Technique |
Output specification |
4~20mA |
Output linear |
Better than 0.05% |
Comprehensive accuracy |
Better than 0.2% |
Output ripple |
≤5mVp-p |
AD sampling |
40SPS |
Input load |
1~4 |
Excitation voltage |
6VDC |
Output load |
≤500ΩOutput load resistor |
Power supply |
15~26VDC |
Power waste |
≤0.2W |
Operation temp range |
-20~60℃ |
Weight approx. |
0.45kg |
Material |
Aluminum ally |
IP Class |
IP65 |
Zhengzhou Sinoder Indutech Machinery Co., ltd (hereafter referred to as "Sinoder") is a joint-stock machinery manufacturing enterprise, integrating industrial scientific research, production and marketing. The company is located in the Industry Area Zone of Zhengzhou, China.
1.Pre-sale services:
1) Selecting equipment type;
2) Designing and fabricating the products in accordance with the special requirements of the clients;
3) Training technical personnel for our clients;
4) Providing construction and technology consultations or working out proper construction schemes for those new, special or difficult projects.
2.Services provided during the sale:
Respect our clients; present the clients with ease, relaxation and a surprise; devote ourselves to improve the total value of our clients.
1) Checking products acceptance ahead of delivery;
2) Introducing the service system to our clients.
3. After-sale services:
Improve the added value of our products, and let the clients free from the using troubles:
1) Assisting the clients preparing for the first construction scheme;
2) Installing and testing the equipments;
3) Training the first-line operators on site;
4) Examining the equipment regularly;
5) Taking the initiatives to eliminate the failure(s) rapidly at site;
6) Distributing the guarantee fittings door-to-door;
7) Providing technical exchanging;
8) Providing maintenance for big item
1.Waterproof packing with the international export standard by 20ft, 40ft, 40hp container.
2. Equipment Fittings, Electric Motor and Power Cabinet will be packed in Wooden Case or Iron Box. Other Equipment will be packed by Color-Stripes Plastic Cloth.
3. Or as per customer's requirements.
If you want to know more information , Pls to contact us
Tel: 0371 55933391 Fax: 0371 55919082
