Help CenterSupply Cold Coal Gas Gasifier / Single Stage Coal Gasifier for Heating
Related Products
-
Anthracite Coal Gasifier/ Gas Furnace With Good QualityUS$ 1,200 - 12,000MOQ: 1 Set -
Fast Delivery High Quality Biomass Boiler PriceUS$ 3,500 - 10,000MOQ: 1 Set
-
Double Stage Coal Gasifier / Coal Gasifier Uses Air and Vapor as the Gasifying Agents to Produce Mixed Gas.US$ 1,200 - 12,000MOQ: 1 Set
-
Supply Wok Burner for Restaurants Wood Pellet Burner for Steam Boiler to Replace Fuel Oil and Fuel Gas and Fuel Coal FurnUS$ 3,500 - 10,000MOQ: 1 Set
-
New Full Automatic High Efficiency Energy Saving Biomass Burner for Asphalt Mixing PlantUS$ 3,500 - 10,000MOQ: 1 Set
Specifications
.1. quick start & small invest2.safe and pro-environment
3.save 20% fuel
.Introduction of coal gas gasifier ?
The coal gas gasifier is a equipment that use coking coal,anthracite, weak conherent charcoal as fuel, air and steam as vaporization medicinalpreparation to produce gas as heat source.
It is widely used in the enviroment-friendly and energy-saving technological renovation of gas-processing heating furnace, gas forging furnace, gas crucible furnace, gas mold furnace, grilled ladle gas furnace, sand resin heating gas regenerater, glass melting gas furnace, ceramic gas furnace, smoke exausting refractory kiln and tunnel kiln, as well as the renovation of furnaces that burn coal or oil, kilns, and equipment that needs heat such as metallurgy, chemical industry, allumim, fire-resistant materials, glass products and existing kiln,with very good effect.
Working principle :
Use the scientific technology structure to analyze water molecules, produced hydrogen (H2)to combuste, oxygen (02) for helping combustion, so that the temperature increased rapidly in combustion studio. This cycle can make fuel burn fully in the oven, and produce great heat value. Because of the full combustionand and swirl cyclone combustion technology in the combustion chamber, the coal gas genetor can achieve high temperatures, avoid the emission of harmful gases, such as C0, C02, N0, S02, smoke removal, dust removal, desulfurization, achieve the requirements of environmental protection department.
Feature :
1)Convenient to remove slags;
2) Easy to operate and maintain;
3) Long service life;
4) Continual and cyclical manufacturing;
Technical specification :
ame |
Coal gasifier |
||||||||||
Internal Diameter(m) |
0.6 |
0.6 |
1 |
1.2 |
1.4 |
1.6 |
1.8 |
||||
Sectional Area(m³) |
0.28 |
0.5 |
0.78 |
1.13 |
1.53 |
2 |
2.54 |
||||
Fuel Consumption(kg/h) |
60-90 |
100-130 |
150-210 |
220-265 |
250-300 |
350-450 |
480-580 |
||||
Gas Production(Nm/h) |
180/270 |
300/270 |
450/630 |
600/295 |
750/900 |
1050/1350 |
1440/1740 |
||||
Cleaner Way |
Hand Cleaner |
||||||||||
Internal Diameter(m) |
2 |
2.2 |
2.4 |
2.6 |
2.8 |
3 |
3.2 |
||||
Sectional Area(m³) |
3.14 |
3.29 |
4.52 |
5.3 |
6.15 |
7.06 |
8.03 |
||||
Fuel Consumption(kg/h) |
600-850 |
900-1000 |
1000-1200 |
1200-1500 |
1600-1800 |
2400-2600 |
2400-2600 |
||||
Gas Production(Nm/h) |
1800/2550 |
2700/3000 |
3000/3600 |
3600/4500 |
4800/5400 |
6000/7200 |
7200/7800 |
||||
Cleaner Way |
Machine Cleaner |
Worm Gear |
|||||||||
Fuel Standard |
anthracite,bitumite, lignite,coke |
||||||||||
Gasification Agent |
Gas + Water |
||||||||||
Gas Caloricity(Kj/nm) |
5025-5650(1200-1450 Kcal) |
||||||||||
Gas Outlet Temperature( |
200-450 Can be adjusted according to the coal quality situation) |
||||||||||
Gas Outlet Pressure(Pa) |
900 |
||||||||||
Saturation Temperature() |
45-70 |
||||||||||
Quality Of Coal |
<70 |
||||||||||
Working Pressure |
Heat should be over 6000 Kcal,Per kilogram of coal can produce three cubic coal gas |
||||||||||
Zhengzhou Sinoder Indutech Machinery Co., ltd (hereafter referred to as "Sinoder") is a joint-stock machinery manufacturing enterprise, integrating industrial scientific research, production and marketing. The company is located in the Industry Area Zone of Zhengzhou, China.
The main products cover industrial drying machines,industrial crushing machines, mineral processing machines, brick machines, biomass energetic machines, environment protection equipment, food oil press machines and other mechanical equipment. Our key product include stone crusher,sand maker, stone washing machine, ball mill, flotation cell, AAC block plant, rotaty drying machines, biomass burner, coal gasifier, oil press machine, packaging machine, breeding machines, fertilizer and pellets machine and other machines.
Sinoder offer not only products with good quality and competitive price, but also top service and solution.
Website:
1.Waterproof packing with the international export standard by 20ft, 40ft, 40hp container.
2. Equipment Fittings, Electric Motor and Power Cabinet will be packed in Wooden Case or Iron Box. Other Equipment will be packed by Color-Stripes Plastic Cloth.
3. Or as per customer's requirements.
If you want to know more information , Pls to contact us
Tel: 0371 55933391 Fax: 0371 55919082
1.Pre-sale services:
1) Selecting equipment type;
2) Designing and fabricating the products in accordance with the special requirements of the clients;
3) Training technical personnel for our clients;
4) Providing construction and technology consultations or working out proper construction schemes for those new, special or difficult projects.
2.Services provided during the sale:
Respect our clients; present the clients with ease, relaxation and a surprise; devote ourselves to improve the total value of our clients.
1) Checking products acceptance ahead of delivery;
2) Introducing the service system to our clients.
3. After-sale services:
Improve the added value of our products, and let the clients free from the using troubles:
1) Assisting the clients preparing for the first construction scheme;
2) Installing and testing the equipments;
3) Training the first-line operators on site;
4) Examining the equipment regularly;
5) Taking the initiatives to eliminate the failure(s) rapidly at site;
6) Distributing the guarantee fittings door-to-door;
7) Providing technical exchanging;
8) Providing maintenance for big item
