Supply Coal/Biomass Fired DZL coal fired steam boiler -SINODER
- 100 Set / Sets per Month
- Shanghai/ Tianjing/ Qingdao
- T/T
- Mini animal feed grinding machine , corn powder hammer mill
- Mini type corn hammer mill , feed grinding machine for sell
- Factory direct sell small feed hammer mill , corn grinding machine
- Large capacity gum arabic hammer mill with cyclone
- Double Win agricultural hammer mill for sale,grain hammer mills for sale
- Ce approval Rice husk hammer mill machine/corn hammer mill/maize grinding hammer mill
Product Details
Condition: | New | Type: | Natural Circulation | Usage: | Industrial |
Structure: | Fire Tube | Pressure: | High Pressure | Style: | Horizontal |
Fuel: | Coal-fired | Place of Origin: | Henan, China | Brand Name: | SINODER BOILER |
Model Number: | WNS | Output: | Steam | Dimension(L*W*H): | 4.17*2.1*2.96M |
Weight: | 10T | Certification: | ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
DZL coal fired steam boilerHot Water Boiler gas fired steam boiler Oil Fired Water Tube Boiler (Saturated / Super-Heated Steam
Waste Heat Water Tube Boiler (Saturated / Super-Heated Steam)
Gas and Liquid Fuel (Warm / Hot Water) Boilers Horizontal biomass boiler
Supply Industrial Steam Boiler, Electric Heating Boiler, Oil Fired Boiler, Gas Fired Boiler, coal fired steam boiler -SINODER
1. Oil /Gas Fired Boiler 2. Coal/Biomass Fired Grate type Boiler
3. Power Station Boiler 4. Thermal Oil Boiler
5. Waste Heat Recovery Boiler 6. Coal Water Slurry Fired Boiler
7.Hot Air Stove 8.Electric Boiler
9.Fluid Bed Boiler 10. Boiler Auxiliary Equipment
Industrial Boiler General Description | |
1. Product description: | coal or biomass fired Industrial boiler industrial steam boiler prices |
2. Rated capacity: | 0.3 to 30ton/hour |
3. Rated pressure: | 1.25Mpa |
4. Rated temperature: | 194°C |
5.Fuel: | coal, gas, oil, biomass etc |
6.Model: | WNS, DZL, SZL etc. industrial steam boiler or hot water boiler |
Terms | |
1. Price Term: | FOB, CIF, DAF etc. |
2. Manufacturing Code: | China GB standard |
3. Delivery Time: | 10-40days |
4. Power supply: | 380V/230V/260V/440V, 60Hz/50Hz, 3Phase |
After Sales Service: | 2years to boiler main part with full life after-sales sales and spare parts available |
Certification: | Boiler quality certificates, installation drawings, user manual etc. |
The technical parameters:
Item | Model | DZL-1-0.7-AII | DZL1-1.0-AII | DZL2-1.0-AII | DZL2-1.25-AII | DZL2-1.6-AII | DZL3-1.25-AII | DZL4-1.25-AII | DZL6-1.25-AII | |||
Rated steam evaporation | t/h | 1 |
| 2 | 2 | 2 | 3 | 4 | 6 | |||
Rated steam pressure | Mpa | 0.7 | 1 | 1 | 1.25 | 1.6 | 1.25 | 1.25 | 1.25 | |||
Rate steam temperature | 'C | 170 | 184 | 184 | 193 | 204 | 193 | 193 | 193 | |||
Water supply temperature | 'C | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | |||
Heating area | main body | emissions |
| 614 | 6.14 | 6.8 | 16.8 | 16.8 | 17 | 24.68 | 37.2 | |
convection | m2 | 214 | 21.4 | 44.5 | 44.5 | 44.5 | 50.1 | 71.07 | 107.5 | |||
chain grate effctive area | m2 | 2.4 | 2.4 | 3.42 | 3.42 | 3.42 | 5.6 | 6.6 | 7.6 | |||
fuel consumption | kg/h | 113 | 115 | 223 | 227 | 230 | 380 | 450 | 670 | |||
maximum transportation size | mm | 4747*2131*2866 | 4745*2131*2866 | 6051*2482*3051 | 6051*2481*3052 | 6052*2502*3151 | 6202*2802*3421 | 7456*2921*3431 | 7889*3032*3456 | |||
maximum installation size | mm | 4745*2555*3065 | 4746*2555*3066 | 6051*3622*4234 | 6051*3622*4236 | 6051*3841*4236 | 6204*4507*4771 | 7455*4241*5083 | 7889*4573*5436 | |||
boiler room size | m | 10*9*6 | 10*9*6 | 12*10*7 | 12*10*7 | 12*10*7 | 12*10*7 | 14*11*7 | 14*11*7 | |||
maximum transportation weight | t | 14.4 | 14.5 | 19.7 | 19.7 | 21.8 |
Usage: for chemical plant, Printing and Dyeing industries, rice mill, Paper making, Leather Factory, disinfection, food processing, textile industries, laundry, hotel, school, greenhouse heating, central heating etc.
Supply Cope of industrial Steam Boiler | |
Product name | Quantity (set) |
I. Boiler main part | 1 |
1. Draft fan | 1 |
2. Forced fan | 1 |
3. Electric control box | 1 |
4. Valve & Gauge used on boiler main part | 1 |
5. Grate speed reducer | 1 |
6. Water pump | 2 |
7. Steam dividing equipment | 1 |
8. Smoke chimney | 1 |
9. Smoke ducting | 1 |
10. Economizer | 1 |
11. Fuel feeder | 1 |
12. Slag remover | 1 |
13. Dry-type Dust Collector | 1 |
14. Water treatment equipment | 1 |
The above is standard; Other equipments are available, like Wet scrubber, air-preheater, deaerator, pressure tank, condensed water recycling equipment, heat exchanger etc. |
Company honor and qualification:
1, A-class boiler production, design qualification;
2, Three kinds of pressure vessel production, design qualification;
3, level 1 boiler installation qualification
4, ISO 9001 quality management system certification
ISO 14001 environmental management system certification
ISO 18001 occupational health management system certification,
5.China's environmental protection product certification.
6, AAA credit rating
RFQ
(1).Q:Where is your factory located? How can I visit there?
A: our factory is located on Zhengzhou, henan, China
All our clients, from home or abroad, are warmly welcome to visit us!
(2).Q:What is the type of your products?
A: Coal-fired boiler and oil-fired boiler, gas boiler, etc
DZH/DZL/SZL/SZS/WNS/YGL/YGW/YLLseries
(3).How long do you need the delivery time
A: About 30 days,According to the product.
(4).What is the MOQ?
A: Our MOQ is 1 set ,but if you have other requirements, please contact us.
(5).Payment Terms
A.L/C( high bank charge, not suggest , but acceptable )
B.T/T( 70% deposit , 30% before shippment)
