Home > Products > Coal Gasification Machinery > Biomass gasifier power plant used in coal-fired, fuel boilers, kiln, metallurgy, chemical industry, aluminum.
Biomass gasifier power plant used in coal-fired, fuel boilers, kiln, metallurgy, chemical industry, aluminum.
- 120 Set / Sets per Month
- Qingdao Tianjin Shanghai
- T/T
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | SINODER |
Model Number: | ALL KINDS FOR YOUR NEEDS | Usage: | Oxygen | Production Rate: | REFER TO THE MODEL |
Voltage: | REFER TO THE MODEL | Power(W): | REFER TO THE MODEL | Weight: | REFER TO THE MODEL |
Dimension(L*W*H): | REFER TO THE MODEL | Certification: | ISO | Warranty: | 18 months |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
biomass gasifier power plant1.High efficiency
2.High gasification efficiency
3.High heating value
4.Higher autoimm
Introduction:
Biomass gasifier power plant used in coal-fired, fuel boilers, kiln, metallurgy, chemical industry, aluminum.
Coal gasification is the foundation of gasifying agent and the carbon. The gasifying agent(water vapor and air mixture) flowing through the hot fixed-bed of combustion coal, there are series chemical reaction process. Gasifying agent contained oxygen and steam reaction with the carbon to produce O2 , H2 , CH4, C2H4, N2 among them , the CO H2CH4 ,CmHn are combustible gases.
It is widely used in the enviroment-friendly and energy-saving technological renovation of gas-processing heating furnace, gas forging furnace, gas crucible furnace, gas mold furnace, grilled ladle gas furnace, sand resin heating gas regenerater, glass melting gas furnace, ceramic gas furnace, smoke exausting refractory kiln and tunnel kiln, as well as the renovation of furnaces that burn coal or oil, kilns, and equipment that needs heat such as metallurgy, chemical industry, allumim, fire-resistant materials, glass products and existing kiln,with very good effect.
Features:
Meet the environmental protection indexes,
Safely and reliably to use,
Do not be limited by the kind of coal,
Use the special combustor,
Lighten the labor intensity
Working principle:
When the coal gas producer working, coal is put into the furnace body from top then moving from top to bottom, Gasifying agent ( air and steam) move from the bottom up, physical and chemical reaction are happened during the furnace chamber.
Advantages:
1. High efficiency
2. Wide adaptability of raw materials
3. High heating temperature
4. No pollution with high environmental benefits
Main Technical Parameter:
Model | HJMQIV-0.8 | HJMQIV -1.0 | HJMQIV -1.3 | HJMQIV -1.6 |
Inner Dia of hearth (mm) | 800 | 1000 | 1300 | 1600 |
Capacity of gas (CNJ/h) | 180-260 | 270-410 | 460-700 | 800-1100 |
Raw material | Anthracite, soft coal, coke, and etc. | |||
Size of raw material (mm) | 10-30 | 30-50 | ||
Consume of coal (kg/h) | 20-50 | 70-120 | 100-200 | 200-300 |
Heat effective | 78% | |||
Blast pressure (Pa) | 3500 | |||
Gas pressure (Pa) | 1470 | |||
Temperature of output gas (°C) | 400-500 | |||
Calorific value of gas (Kilo calorific /m3) | 1250-1500 | |||
Pressure of output(Pa) | <1200 | |||
Ash handling | Automatically | |||
Feeding | By belljar |
Zhengzhou Sinoder Indutech Machinery Co., ltd (hereafter referred to as "Sinoder") is a joint-stock machinery manufacturing enterprise, integrating industrial scientific research, production and marketing. The company is located in the Industry Area Zone of Zhengzhou, China.
The main products cover industrial drying machines,industrial crushingmachines, mineral processing machines, brick machines, biomass energetic machines, environment protection equipment, food oil press machines and other mechanical equipment. Our key product include stone crusher,sand maker, stone washing machine, ball mill, flotation cell, AAC block plant, rotaty drying machines, biomass burner, coal gasifier, oil press machine, packaging machine, breeding machines, fertilizer and pellets machineand other machines.
Sinoder offers not only products with good quality and competitive price, but also possesses the powerful ability in developing the new products and top service.
Sinoder has independent export rights and offices in many countries & areas. Our products have passed CE certificate, exported to Russia, Kazakhstan, Azerbaijan, Turkey, Kuwait, South Africa, Egypt, Vietnam, Malaysia, India, Indonesia, Australia, Korea, Canada, EU, etc. with annual sale 520 million RMB, earning foreign exchange USD 28 million.
Packaging Detail:
Export standard container or nude package or in bulk or according to your order requirements, or we can give you the best suggestion.
Delivery Detail:
Within15--30 working days after receiving your 30% order payment
BSET SERVICE FOR CUSTOMERS:
1. Small trial order are acceptable for you to check our quality and service;
2. Bigger order with bigger discount;
3. Professional guidance are available all the time;
4. We can also help you to do ENGENEERING TEST in our own laboratory.
5. Professional technicians and skilled workers can promise you the top quality of world class;
6. Highly inspecting equipments in every working procedure, quality comes first;
7. Fast & Safe delivery .
Welcome to our factory in ZhengZhou, Henan province, China to have a visit.
To choose the appropriate Biomass gasifier power plant for you, we need to know the following information:
1.Material to be processed?
2.Capacity(tons or kg or litter per hour or day)?
3.Local power supply(voltage and frequency)?
4.Other special requirements.
If you want to know more information about the Biomass gasifier power plant and other machinery, pls do not hesitate to contact us.
