Specifications
Sinoder Supply Briquetted coal gas generator machine furnace1. for coal Gasification fuel
2. High quality with good experienc
Sinoder Supply coal gas generator machine furnace/ coal gasifier for coal Gasification fuel
Sinoder Supply coal gas generator furnace/ coal gasifier for coal Gasification fuel
Coal Gasifier is advanced equipment for producing mixed gas with water and steam as gasifying agent This machine is applicable for gasifying fuel like coking coal or coke Coal Gasifier is widely used as heating furnace in mechanical metallurgy, chemical.
Zhengzhou Sinoder Indutech Machinery Co., ltd (hereafter referred to as "Sinoder") is a joint-stock machinery manufacturing enterprise, integrating industrial scientific research, production and marketing. The company is located in the Industry Area Zone of Zhengzhou, China.
The main products cover industrial drying machines,industrial crushing machines, mineral processing machines, brick machines, biomass energetic machines, environment protection equipment, food oil press machines and other mechanical equipment. Our key product include stone crusher,sand maker, stone washing machine, ball mill, flotation cell, AAC block plant, rotaty drying machines, biomass burner, coal gasifier, oil press machine, packaging machine, breeding machines, fertilizer and pellets machine and other machines.
Briquetted Coal Gasification Producer
WHAT IS GASIFICATION?
Gasification is a process of partial combustion & reduction which converts solid combustible material into Gaseous fuel. Thus gasified fuel can be transported to user point and can be burnt efficiently. It is a Thermo Chemical Conversion. The equipment used for this process is called Gasifier. The Gasifier is extensively used for bio-mass and coal gasification.
Coal Gasifier Working Principle
Coal gasifier parameters
| odel | QM0.8 | QM1.0 | QM1.2 | QM1.5 | QM1.6 | QM1.8 | QM2.0 | QM2.4 | QM2.6 | QM3.0 | QM3.2 |
| Chamber diameter(mm) | 800 | 1000 | 1200 | 1500 | 1600 | 1800 | 2000 | 2400 | 2600 | 3000 | 3200 |
| Hearth active surface(m2) | 0.5 | 0.785 | 1.13 | 1.77 | 2.01 | 2.54 | 3.14 | 4.52 | 5.31 | 7.07 | 8.04 |
| Suirable fuel | weak coherent gas carbon,anotherracite,burnt carbon | ||||||||||
| Fuel granularity(mm) | 25-80 | ||||||||||
| Fuel consumption quantitykg/h | 40-100 | 70-140 | 120-190 | 160-350 | 350-460 | 500-600 | 500-720 | 700-1040 | 850-1200 | 1700-2000 | 1800-2200 |
| Gasifying agent | Air ,steam | ||||||||||
| Gas yieldNm³/h) | 140-350 | 245-490 | 420-670 | 560-1200 | 1200-1600 | 1500-2100 | 1750-2500 | 2500-3600 | 3000-4300 | 6000-7000 | 6500-7500 |
| Gas calorific valu(Kj/Nm³ | 5020-5670 | 5020-6000 | |||||||||
| Water jacket heating area() | 4.02 | 5.02 | 6.78 | 10.37 | 11.06 | 12.44 | 17.58 | 21.87 | 23.69 | 30.16 | 32 |
| Steam outputkg/h | 60 | 80 | 130 | 200 | 220 | 260 | 350 | 420 | 600 | 840 | 200 |
| Gas outlet temperature() | (400-500)Plants related with the coal | (400-500)Plants related with the coal | |||||||||
| Gas outlet pressure(Pa) | 1000 | 980-1470 | 1470-1960 | 980-1470 | |||||||
| Gas exportation diameter(mm) | 219 | 325 | 325 | 426 | 426 | 529 | 630 | 720 | 820 | 1020 | 900 |
| Air pressure(Pa) | 3000 | 4000 | 3000 | ||||||||
| Saturated air temperature() | 50-60 | 50-65 | |||||||||
| Ashpan rotational speed(r/h) | 0.177-1.77 | ||||||||||
| Equipment gross weight(t) | 3.5 | 4.5 | 5 | 7.5 | 10 | 20 | 23.4 | 29.8 | 32 | 37.6 | 16 |
coal gasifier working site
1.Pre-sale services:
1) Selecting equipment type;
2) Designing and fabricating the products in accordance with the special requirements of the clients;
3) Training technical personnel for our clients;
4) Providing construction and technology consultations or working out proper construction schemes for those new, special or difficult projects.
2.Services provided during the sale:
Respect our clients; present the clients with ease, relaxation and a surprise; devote ourselves to improve the total value of our clients.
1) Checking products acceptance ahead of delivery;
2) Introducing the service system to our clients.
3. After-sale services:
Improve the added value of our products, and let the clients free from the using troubles:
1) Assisting the clients preparing for the first construction scheme;
2) Installing and testing the equipments;
3) Training the first-line operators on site;
4) Examining the equipment regularly;
Contact Sinoder
If you want to know more information about the Ring Die Wood Pellet Mill and other machinery, pls do not hesitate to contact us
