hd Sdi 1080p Camera ,hdmi Cctv Camera Cctv Panasonic Cameras

Name: hd Sdi 1080p Camera ,hdmi Cctv Camera Cctv Panasonic Cameras
Brand: Kaansky
SKU: 122044353

US$ 50 - 160 MOQ: 10 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Kaansky

Model Number:

KST-HI-A3

Shenzhen Kaansky Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Kaansky

Model Number KST-HI-A3

Type Digital Camera

Style Bullet Camera

Sensor CMOS

Technology Infrared

Special Features Waterproof / Weatherproof

Specifications

SDI HD camera 1/3"Sony CMOS IMX122 Sensor
support 2 Megapixels 1080P
HD-SDI output,real time coaxial cable Transmission

SDI HD 2.0 Megapixel CMOS camera with 1080P high resolution

Name: Full HD SDI camera

ITEM		HI-A3-SDI2001
Imaging Sensor		1/3” Panasonic CMOS(MN34041PL)
Total Pixels		2010(H) x 1108(V) = 2,227,080 (pixel)
Active pixels		1944(H) x 1092(V) = 2,122,848 (pixel)
Scanning system		Progressive Scan
Resolution		Digital ; 1920x1080p(1080p/30fps) , 1280x720p(720p/60fps) More than 1000 TVL(1080p)

Min. illumination		Color : 1.0 lux , BW : 0.5lux Color DSS : 0.002 lux , BW DSS : 0.001 lux

S/N Ratio		More than 50dB (AGC off)
Video Output		HD-SDI Analog : NTSC, PAL(w/o WDR)

LENS		DC(ALC)/Manual(ELC)
BRIGHTNESS		0 ~ 20
SHUTTER		AUTO/MANUAL(1/30(25)~1/6000)
SENS-UP		OFF/x2/x3/x4/x5/x6/x7/x8
AGC		0 ~ 20
BACKLIGHT		OFF/HLC/BLC/WDR
DAY&NIGHT		AUTO/COLOR/B&W/EXT.
WHITE BAL.		AUTO/AUTOext/PRESET/MANUAL
DNR		OFF/LOW/MIDDLE/HIGH
SHARPNESS		0 ~ 10
MIRROR		ON/OFF
FLIP		ON/OFF
D-WDR		OFF/LOW/MIDDLE/HIGH
SHADING		ON/OFF
PRIVACY		ON(32 Points)/OFF
MOTION		ON/OFF
OUTPUT MODE		720P/1080P
FRAME RATE		25 FPS/30 FPS
CVBS		NTSC/PAL
LANGUAGE		ENG/CHN
Power		DC12V±10%
Video Output(HD-SDI)		MMCX Connector
Storage Temperature		-20°C ~ +60°C (Humidity : 0%RH ~ 90%RH)
Dimension (H x V x T)		38mm x 38mm x 1.2mm
