2mp 1080p Hikvision hd Coaxial Tvi Led Array Camera Cctv

Name: 2mp 1080p Hikvision hd Coaxial Tvi Led Array Camera Cctv
Brand: Kaansky
SKU: 122042401

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Kaansky

Model Number:

KST-HI-E4-TVI

Shenzhen Kaansky Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Kaansky

Model Number KST-HI-E4-TVI

Type Analog Camera

Style Bullet Camera

Sensor CMOS

Technology Infrared

Special Features Other, Coaxial hd analog camera

Specifications

TVI camera
Professional cctv camera manufacturer
CE,FCC,RoHS and ISO9001 certificate
Accept OEM order,
Fast delivery

Features:

High speed, long distance real-time transmission

Day/Night(ICR), AWB, AGC, BLC, 2D/3D-DNR

over-coaxial-cable analog HD video transmission

720P/960P/1080P Resolution

IR Distance80M
Adopting 6PCS HLED IR Leds
Lens:4mm
Dual glass, no IR diffusion and fog
IP66, outdoor installation

Model		HI-E3-TVI1002	HI-E3-TVI1301	I515-TVI2001
Camera	Image Sensor	1/2.9” Progressive Scan CMOS	1/3” 1.37Mega Progressive Scan CMOS	1/3” 2.0Mega Progressive Scan CMOS
	Effective Pixels	1280(H)×720(V)	1312(H)×1069(V)	1956(H)×1266(V)
	Video Frame Rate	25fps@720P	50fps@720P	1080p@25fps/1080p@30fps
	Electronic Shutter	PAL 1/25-1/100, 000Sec; NTSC 1/30-1/100, 000Sec	PAL 1/50-1/50, 000Sec; NTSC 1/60-1/50, 000Sec	PAL 1/25-1/50, 000Sec; NTSC 1/30-1/50, 000Sec
	Synchronization	Internal
	Mini. Illumination	0.001Lux/F1.2(AGC ON), 0Lux IR on		0.001Lux @ (F1.2,AGC ON),0 Lux with IR 0.0014Lux @ (F1.4,AGC ON),0 Lux with IR
	Video Output	1-channel BNC HDTVI high definition video output
	Max. IR LEDs Length	80m
	IR LEDs	6pcs HLED
	Lens	4mm
OSD	Noise Reduction	No OSD		3D (Low, Middle, High,OFF)
	AGC			Low, Middle, High,OFF
	White Balance			Auto/ Manual/AWC-SET
	WDR			D-WDR
	Day/Night			Auto(ICR) / Color / B/W
	Motion			ON/OFF , 4 ZONE
	Privacy			ON/OFF , 8 ZONE
	Language			Chinese/English/Japanese/ Korean/France/Italy/Spanish/Geman/Russia/ Poland/Turkish/...16country language
	Function			Smart IR, D-Zoom,Sharpness, D-flog. Mirror, Freeze, Smart D-Zoom, Neg.Image
Basic	Transmission Distance	Over 500m via 75-3 coaxial cable
	Power Supply	DC12V±15%
	Ingress Protection	IP66
	Power Consumption	Max 4W
	Working Environment	-20°C~+65°C / Less than 90%RH
	Weight	1.2kg
