IHF Series General / explosion-proof fluorine plastic chemical centrifugal pump (liner F46)
IH chemical pump is a single-stage single suction anti-corrosive centrifugal pump (axial suction ) to transport the corrosive liquid which doesn't contain granule and is similar with the water in adherence, it's label rate and size meets with the standard of ISO2858. And the technology condition meets with the standard of GB/T5656-1994. It's features various performance, high efficiency and easy access to repair. The efficency is 5 % higher than that of the model F. It is the preferentially-recommended product.
The Medium temperature is between -20 º C and 120º C. The additional measurements in the mechanical seal and cooling measurement can ensure transporation of higher temperature of medium. It is widely used at the industries to transport kinds of corrosive medium and the medium similar with water which must be immune to pollution such as petroleum, chemistry, metallurgy, syn-thetic fiber, pharmacy, foodstuff, waste water treatment.
Technical Parameters
| 1.Flow Rated Range:6.3-400m³/h |
| 2.Head delivery:20-100m |
3.Matched Power:1.5-90KW |
| 4.Operating temperature:≤150°c |
|
speed n=2900 r/min |
speed n=1450 r/min |
||||||||
PUMP MODEL |
FLOW |
HEAD |
MOTOR POWER |
NSHP(m) |
EFF.(%) |
FLOW |
HEAD |
MOTOR POWER |
NSHP(m) |
EFF.(%) |
IHF40-25-125 |
6.3 |
20 |
1.5 |
3.0 |
51 |
3.2 |
5 |
0.55 |
3.0 |
32 |
IHF40-25-160 |
6.3 |
32 |
2.2 |
3.0 |
46 |
3.2 |
8 |
0.55 |
3.0 |
28 |
IHF40-25-200 |
6.3 |
50 |
5.5 |
3.0 |
39 |
3.2 |
12.5 |
0.55 |
3.0 |
23 |
IHF40-25-250 |
6.3 |
80 |
7.5 |
3.0 |
41 |
3.2 |
20 |
1.5 |
2.0 |
20 |
IHF50-32-125 |
12.5 |
20 |
2.2 |
3.0 |
51 |
6.3 |
5 |
0.55 |
3.0 |
45 |
IHF50-32-160 |
12.5 |
32 |
4 |
3.0 |
46 |
6.3 |
8 |
0.55 |
3.0 |
40 |
IHF50-32-200 |
12.5 |
50 |
7.5 |
3.0 |
39 |
6.3 |
12.5 |
1.1 |
3.0 |
33 |
IHF50-32-250 |
12.5 |
80 |
11 |
5.0 |
35 |
6.3 |
20 |
1.5 |
5.0 |
30 |
IHF65-50-125 |
25 |
20 |
3 |
3.5 |
62 |
12.5 |
5 |
0.55 |
3.5 |
55 |
IHF65-50-160 |
25 |
32 |
5.5 |
3.5 |
57 |
12.5 |
8 |
1.1 |
3.5 |
51 |
IHF65-40-200 |
25 |
50 |
11 |
3.5 |
52 |
12.5 |
12.5 |
1.5 |
3.5 |
46 |
IHF65-40-250 |
25 |
80 |
18.5 |
3.5 |
50 |
12.5 |
20 |
3 |
3.5 |
43 |
IHF80-65-125 |
50 |
20 |
5.5 |
4.0 |
69 |
25 |
5 |
1.1 |
4.0 |
64 |
IHF80-65-160 |
50 |
32 |
11 |
4.0 |
67 |
25 |
8 |
1.5 |
4.0 |
62 |
IHF80-50-200 |
50 |
50 |
15 |
4.0 |
63 |
25 |
12.5 |
2.2 |
4.0 |
57 |
IHF80-50-250 |
50 |
80 |
30 |
4.0 |
66 |
25 |
20 |
5.5 |
4.0 |
51 |
IHF100-80-125 |
100 |
20 |
11 |
4.5 |
66 |
50 |
5 |
1.5 |
4.5 |
64 |
IHF100-80-160 |
100 |
32 |
15 |
5.0 |
71 |
50 |
8 |
2.2 |
5.0 |
68 |
IHF100-65-200 |
100 |
50 |
30 |
5.0 |
67 |
50 |
12.5 |
5.5 |
5.0 |
64 |
IHF100-65-250 |
100 |
80 |
55 |
5.0 |
65 |
50 |
20 |
7.5 |
5.0 |
62 |
IHF125-80-160 |
160 |
32 |
30 |
5.0 |
70 |
80 |
8 |
5.5 |
5.0 |
74 |
IHF125-100-200 |
200 |
50 |
55 |
5.0 |
65 |
100 |
12.5 |
11 |
5.0 |
71 |
IHF125-100-250 |
200 |
80 |
75 |
5.0 |
73 |
100 |
20 |
15 |
5.0 |
73 |
IHF125-100-315 |
|
|
|
|
|
100 |
32 |
18.5 |
3.0 |
60 |
IHF150-125-250 |
|
|
|
|
|
200 |
20 |
22 |
7.0 |
67 |
IHF150-125-315 |
|
|
|
|
|
200 |
32 |
45 |
7.0 |
65 |
IHF200-150-250 |
|
|
|
|
|
400 |
20 |
55 |
7.5 |
69 |
IHF200-150-315 |
|
|
|
|
|
400 |
32 |
75 |
7.5 |
68 |
IHF200-150-400 |
|
|
|
|
|
400 |
50 |
110 |
7.5 |
74 |
Model Meaning
