CQF Light Engineering Small Plastic Magnetic Driving Pump are new products to apply the working principle of permanent magnetism coupling into the centrifugal pump, characterized by reasonable design, advanced process, full seal, zero leakage and corrosion resistance.Their performance can reach the advanced level of foreign like product.
The magnetic pump adopts the static seal instead of the dynamic seal so that its flow-through parts are in a state of complete seal, thus thoroughly solving the unavoidable shortcoming of running, bubbling and dropping of the mechanical seal of other pump types. It is made of such materials as engineering plastics,corundum ceramic and stainless steel with corrosion resistance and high strength, so it has a strong resistance to corrosion and can free the transported medium from being polluted.
The magnetic pump is characterized by compact structure, attractive appearance, small volume, low noise, reliable operation and being easy for use and maintenance. It can be widely applied in such fields as chemical engeering ,pharmacy, petroleum, electroplating,food,developing and printing of film and photo,scientific institutions and defense industry for drawing rare acid, alkali and oil liquids,poisonous liquid and volatile liquid as well as serving as a fitting for water circulating equipment and filter, especially for drawing the leaky, inflammable and explosive liquid. It′ll be ideal for the explosion-proof motor to work with this pump.
I.Type Designation:
32 CQ (F)(B) -15
32 - Inlet diameter(mm)
CQ - magnetic drive pump
F – for plastic
B - for stainless steel
15 - lift head(m)
II.Range of Application:
Widely applicable for chemical, pharmacy,petroleum,electroplating,scientific research institutions and etc. to handle precious,toxic and volatile liquids,matched to cycle water equipment and filter to handle leaky,inflammable and explosive liquids.
III.Technology Parameters:
Flow:0.9-60m3/h;
Head:3-50m;
Rotary Speed:2900r/min;
Power:0.10-15kw;
Temperature Range:-20-100℃(stainless steel);
0-60 (plastic)
Model |
connection |
Dia. |
Flow |
Head |
Power |
Voltage |
|
|
|
Inlet |
Outlet |
|
|
|
|
|
|
(mm) |
(mm) |
(m^3/h) |
(m) |
(kW) |
(V) |
10CQF-3 |
Intubation connection |
10 |
8 |
0.9 |
3 |
0.025 |
220 |
14CQF-5 |
14 |
10 |
1.2 |
5 |
0.12 |
220 |
|
16CQF-8 |
16 |
10 |
1.8 |
8 |
0.18 |
220 |
|
20CQF-12 |
20 |
15 |
3 |
12 |
0.37 |
220 |
|
14CQF-5 |
14 |
10 |
1.2 |
5 |
0.12 |
380 |
|
16CQF-8 |
16 |
10 |
1.8 |
8 |
0.18 |
380 |
|
20CQF-12 |
20 |
15 |
3 |
12 |
0.37 |
380 |
|
25CQF-15 |
Intubation fast connection or flange connection |
25 |
20 |
5.4 |
15 |
1.1 |
380 |
32CQF-15 |
32 |
25 |
6.6 |
15 |
1.1 |
380 |
|
32CQF-25 |
4.8 |
25 |
1.1 |
380 |
|||
40CQF-20 |
40 |
32 |
10.8 |
20 |
1.5 |
380 |
|
40CQF-20 |
40 |
32 |
10.8 |
20 |
2.2 |
380 |
|
50CQF-25 |
50 |
40 |
12.5 |
25 |
3 |
380 |
|
50CQF-32 |
12.5 |
32 |
4 |
380 |
|||
65CQF-25 |
flange connection |
65 |
50 |
25 |
25 |
4 |
380 |
65CQF-32 |
65 |
50 |
25 |
32 |
5.5 |
380 |
|
