Tri-axle Skeletal Semi-trailer for Container Transportation

Name: Tri-axle Skeletal Semi-trailer for Container Transportation
Brand: LUFENG
SKU: 122025481

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Type:

Semi-Trailer

Material:

Aluminum / Alloy

Certification:

Other, ISO,CCC

Shandong Lufeng Special-Purpose Vehicle Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Type Semi-Trailer

Material Aluminum / Alloy

Certification Other, ISO,CCC

Size 12500mm*2490mm*1600mm

Max Payload 40T

Place of Origin Shandong, China

Brand Name LUFENG

Model Number ST9371TJZ

Specifications

Tri-axle Skeletal Semi-trailer
20f,40ft,45ft,48ft container
Tri-axle 11-pcs leaf spring suspension with equalizer beam

Tri-axle Skeletal Semi-trailer ST9371TJZ

General
Overall Dimension		12500mm2490mm1600mm
Tare Weight		6750kg	Pay Load	40ton
King Pin Setting		1120mm	Rear Overhang	1690mm
Track		1840mm	Wheel base	7080mm+1305mm+1305mm
Running Gear
Suspension		Tri-axle 11-pcs leaf spring suspension with equalizer beam
Tires		11.00R20, 12units
Axles		CNHTC axle, 13T capacity
Brakes		Dual lines pneumatic brake system, WABCO Emergency Relay Valve; T30/30+T30 air chamber; parking brake
Under Frame
Main Beam		I shape, Mild Alloy (16Mn) by Automatic submerged arc welding.
Cross Beam		Mild Alloy Q235
King Pin		Size: 50# (2'') or 90#(3.5’’); Type: welded or assembled
Landing Gear		Single side operation or double side operation, Static capacity 30Ton
Twist Locks		12 lock positions with 8 twist locks
Appendix		1 tool box, length 1.0m
Electrical & Paint
Lights & Reflectors	Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light
Wiring	24V, 6 lines
Air/Elec. Connector	ISO standard air connector, 24V 7 pin plug socket
Paint	color upon request
