Dual-axle Flatbed Semi-trailer ST9261TJZ

Name: Dual-axle Flatbed Semi-trailer ST9261TJZ
Brand: LUFENG
SKU: 122025489

US$ 13,500 - 18,000 MOQ: 1 Set

Key Specifications

Type:

Semi-Trailer

Material:

Steel

Certification:

Other, CCC,ISO

Shandong Lufeng Special-Purpose Vehicle Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

TIANJIN QINGDAO LONGKOU SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Type Semi-Trailer

Material Steel

Certification Other, CCC,ISO

Size 12340mm*2490mm*1600mm

Max Payload 31T

Place of Origin Shandong, China

Brand Name LUFENG

Model Number ST9261TJZ

Specifications

container carrir Flatbed Semi-trailer
1.high quality
2.advanced technology
3.refined service

Product Description

Dual-axle Flatbed Semi-trailer ST9261TJZ

General
Overall Dimension		12340mm2490mm1600mm
Tare Weight		4900kg	Pay Load	31ton
King Pin Setting		1240mm	Rear Overhang	1845mm
Track		1840mm	Wheel base	7950mm+1305mm
Running Gear
Suspension		Dual-axle 11-pcs leaf spring suspension with equalizer beam
Tires		11.00R20, 8units
Axles		CNHTC axle, 13T capacity
Brakes		Dual lines pneumatic brake system, WABCO Emergency Relay Valve; T30/30 air chamber; parking brake
Under Frame
Main Beam		I shape, Mild Alloy (16Mn) by Automatic submerged arc welding.
Cross Beam		Mild Alloy Q235
King Pin		Size: 50# (2'') or 90#(3.5’’); Type: welded or assembled
Landing Gear		Single side operation or double side operation, Static capacity 25Ton
Twist Locks		12 lock positions with 8 twist locks
Flatbed Floor		Checkered sheet, thickness 2.5mm
Toolbox		1 tool box, length 1.5m
Electrical & Paint
Lights & Reflectors	Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light
Wiring	24V, 6 lines
Air/Elec. Connector	ISO standard air connector, 24V 7 pin plug socket
Paint	color upon request
