Product Name | Titanium plates |
Titanium Grade | GR1 GR2 GR3 GR5 GR7 GR9 GR11 |
Standard | ASTM B265,ASTM F67,ASTM F136,AMS4911 |
Material | GR1,GR2,GR3,GR5,GR7,GR9,GR12,GR23 |
Surface | pickling surface, polished surface, black surface |
Material | GR1,GR2,GR3,GR5,GR7,GR9,GR12,GR23 |
Status | Cold rolled(Y)~Hot rolled(R)~Annealed (M)~Solid Status |
Chemical requirements:
Grade | Ti | Chemical composition | |||||||||
|
| Major composition | residual elements (not more than) | ||||||||
|
| Al | V | Sn | Mo | Pa | Fe | C | N | H | O |
Gr1ELI | Bal | / | / | / | / | / | 0.1 | 0.03 | 0.012 | 0.008 | 0.1 |
Gr1 | Bal | / | / | / | / | / | 0.2 | 0.08 | 0.03 | 0.015 | 0.18 |
Gr2 | Bal | / | / | / | / | / | 0.3 | 0.08 | 0.03 | 0.015 | 0.25 |
Gr3 | Bal | / | / | / | / | / | 0.3 | 0.08 | 0.05 | 0.015 | 0.35 |
Gr4 | Bal | / | / | / | / | / | 0.5 | 0.08 | 0.05 | 0.015 | 0.4 |
Gr5 | Bal | 5.5~6.75 | 3.5~4.5 | / | / | / | 0.3 | 0.08 | 0.05 | 0.015 | 0.2 |
Gr5ELI | Bal | 5.5~6.5 | 3.5~4.5 | / | / | / | 0.25 | 0.08 | 0.03 | 0.012 | 0.13 |
Physical properties:
Grade | Mechanical Properties (>%) | ||||||
Tensile Strengh (min) | Yield Strengh (0.2% offset) | Elongation (min %) | |||||
Ksi | Mpa | Min | Max |
| |||
Ksi | Mpa | Ksi | Mpa | ||||
Gr1 | 35 | 240 | 20 | 170 | 45 | 310 | 240 |
Gr2 | 50 | 345 | 40 | 275 | 65 | 450 | 20 |
Gr3 | 65 | 450 | 55 | 380 | 80 | 550 | 18 |
Gr4 | 80 | 550 | 70 | 483 | 95 | 650 | 15 |
Gr5 | 130 | 895 | 120 | 828 | - | - | 10c |
Gr7 | 50 | 345 | 40 | 275 | 65 | 450 | 20 |
Gr9 | 90 | 620 | 70 | 483 | - | - | 15D |
Gr12 | 70 | 483 | 50 | 345 | - | - | 180 |
Features:
1. Low Density and High Specification Strength
2. Excellent Corrosion Resistance
3. Good Resistance to Effect of Heat
4. Excellent Bearing to Cryogenics Property
5. Nonmagnetic and Non-toxic
6. Good Thermal Properties
7. Low Modulus of Elasticity
