titanium mesh plate for skull
- 500 Kilogram / Kilograms per Month
- Shanghai tianjin Hong Kong
- T/T L/C D/P D/A Credit Card PayPal
- 1.5mm Sintered Porous Titanium Plate Filtration Industry
- 0.2 Micron Porous Titanium Sheet for Filtration
- Pem Electrolyzers 0.3mm 0.5mm 0.8mm 1.0mm Diamond Hole Ni200 Metal Nickel Expanded Mesh
- Porous Titanium Sheet for Gas Diffusion Layer
- Titanium Plate With Flow Field For Electrolyzers
- A 10 Micron Ultra-long Microporous Metal Titanium Plate
Product Details
Place of Origin: | Shaanxi, China | Application: | Medical | Thickness: | 0.5mm,0.6mm,1.0mm |
Width: | 300~500mm | Length: | 1200~1500mm | Technique: | Cold Rolled |
Ti (Min): | 99.6% | Brand Name: | BoYang Metal | Model Number: | Titanium Medical Plate |
Product Description
titanium mesh plate for skull
Welcome to
----------------------------------
Baoji BoYang metal material Co.,LTD
The company is located in Baoji, the Titanium City of China. The company is mainly engaged in rare metals processing and machining. And it is also a special manufacturer of nonferrous material sales, products and equipment manufacturing and new products development. We have the followings as our major products and it is with the design and manufacture at the core, such as shaped pieces, titanium plate, titanium bar, titanium wire GR1 GR2 GR3 GR5 GR7 GR9. Moreover, the company has titanium material, titanium standard parts, titanium composite material and other complete product line of nonferrous metal products. The products are widely used in chemical, metallurgy, petroleum, textile, medicine, light industry, environmental protection, sports, mining, marine and other fields. Relying on the strong industry resources, powerful scientific research, the ability to manufacture and a complete industrial chain of titanium industrial manufacturing of “the Titanium City of China", we are keep improving our sales service with our honesty and sincerity, and will do so. We warmly welcome both new and old clients to visit and negotiate with us.
---------------------------------------------------------------------------------------------------------------
Ti grade chemical component
ASTM No. | Fe max | O max | N max | C max | H max | Pd | Al | Bal |
| wt% | wt% | wt% | wt% | wt% | wt% | wt% | Ti |
Grade 1 | 0.2 | 0.18 | 0.03 | 0.1 | 0.015 | - | - | Ti |
Grade 2 | 0.3 | 0.25 | 0.03 | 0.1 | 0.015 | - | - | Ti |
Grade 4 | 0.5 | 0.4 | 0.05 | 0.1 | 0.015 | - | - | Ti |
Grade 5 | 0.4 | 0.2 | 0.05 | 0.1 | 0.015 | - | 5.5-6.7 | Ti |
Grade 7 | 0.3 | 0.25 | 0.03 | 0.1 | 0.015 | 0,12-0.25 | - | Ti |
Grade 9 | 0.25 | 0.15 | 0.02 | 0.05 | 0.015 | - | 2,5-3,05 | Ti |
Mechanical Properties
ASTM Grade | Alloy Composition | Tensile Strength | Yield Strength | Elongation % | ||
ksi | Mpa | ksi | Mpa | |||
Gr1 | Unalloyed Ti ("Pure") 35A -CP1 | 35 | 240 | 25 | 170 | 24 |
Gr2 | Unalloyed Ti ("Pure") 50A -CP2 | 50 | 345 | 40 | 275 | 20 |
Gr4 | Unalloyed Ti ("Pure") 80A -CP4 | 80 | 550 | 70 | 483 | 15 |
Gr5 | Ti 6Al 4V | 130 | 895 | 120 | 828 | 10E |
Gr7 | T-50A 0.15Pd | 50 | 345 | 40 | 275 | 20 |
Gr9 | Ti 3Al 2.5V | 90 | 620 | 70 | 483 | 15F |
Titanium Plate Advantage:
(1)Choose excellent raw material:0 grade Titanium sponge;
(2)Accurate Tolerance:For 0.5~2.0mm thickness,0~0.05mm;For2.0 to 10.0mm,0~0.1mm;
(3)Strengh can be stably controlled at 550(+/-20)Mpa,and Gr5 ,Ti-6Al-4V ELI can be stably controlled at 1000(+/-30)Mpa;
(4)Stable and uniform microstructure:For thickness 1.0~6.0mm,TA3,Gr3 grain size can reach to more than level 8,and TC4,TC4ELI,TC20,Gr5,Ti-6Al-4V ELI ,Ti-6Al-7Nb microstructure can be stably controlled at A1-a4;
(5)100% ultrasonic/turbine flaw detection:100% Eliminate metallurgical defects and non-ferrous impurities.
FAQ
1.Q:Are you a factory or trading company?
A:We are a factory.
2.Q:Where is your factory located? How can I visit there?
A:Our factory is located in Baoji City, Shaanxi Province, China, about 2 hours train from Xi'an.
All our clients, from home or abroad, are warmly welcome to visit us!
3.Q:How can I get some samples?
A: We are honored to offer you samples.
4.Q:How does your factory do regarding quality control?
A:Quality is priority. Hanz people always attach great importance to quality controlling from
the very beginning to the very end.
The first is the raw materials and strict control of spindle the second production process control, the third is the inspection factory.
Why Choose US
-------------------------------------------------
1.Provide free samples.
2.Fast delivery.
3.Guarantee quality.
4.High response rates.
5.Long time maintenance service the product.
6.Terrific after-sales service :24 hours around and 12 month warranty
Wish you success in your work!
=====================================
