Product Details
Place of Origin: | China | Brand Name: | TOPSFLO | Model Number: | TF30A-C |
Theory: | Vacuum Pump | Structure: | Diaphragm Pump | Usage: | Other, liquid |
Power: | Electric | Standard or Nonstandard: | Other, standard,customized | Fuel: | Other, DC power, Battery |
Pressure: | Other, 0.4L/min,vacuum 70kpa | Application: | Other, Printer ink, fireplace,Gas detection devices |
Product Description
Diaphragm liquid corrosion resistance 6V 12V 24V electronic boards ink-jet diaphragm pump
The most advanced design, same concept as KNF, Parker pump, with delicate outlook, small size, compact structure.
- Suitable specifications, precise flowrate
- Excellent inner materials sutiable for various ink
- Ideal for all types of inkjet printer
- Optional for different life span motor
- Adjustable flowrate by 0-5V PWM speed control
Picture | Model | Rated voltage | No-load current | Max Head | Max Vacuum | Max flow | Lifetime |
(VDC) | (A) | (M) | (KPa) | (L/min) | (hrs) | ||
TF30A-A | 6/12/24 | 0.4/0.24/0.15 | ≥10M | -70KPa | water : 0.4 | 3,000 | |
gas : 4 | |||||||
TF30A-C | 6/12/24 | 0.4/0.24/0.15 | ≥10M | -70KPa | water : 0.4 | 15,000 | |
gas : 4 | |||||||
TF30A-D | 6/12/24 | 0.4/0.24/0.15 | ≥10M | -70KPa | water : 0.4 | 15,000 | |
gas : 4 | |||||||
TF30B-H | 6/12/24 | 0.24/0.15 | ≥10M | -60KPa | water : 0.35 | 10,000 | |
gas : 4.5 |
♦ UV ink ♦ Solvent based ink ♦ Oil based ink ♦ Water based ink ♦ MEK ink etc.
•Ideal for All Types of Inkjet Printers
♦ Longer Lifetime
♦ less electromagnetic interference
Equiped with anti-electromagnetic interference capacitors, Topsflo pumps cause little interference to your facility.
♦ less temperature rise
Are you bothered if pump gets heat soon when it's working in your facility? Topsflo adopts the most advanced technology as KNF does, the pump won't get much heat during working,especially outside controller models.
♦ Adjustable flowrate by 0-5V PWM speed control
