C62300 Aluminum Bronze Rods for Ship Building / Naval Dock Components

C62300 Aluminum Bronze Rods for Ship Building / Naval Dock Components thumbnail-1
C62300 Aluminum Bronze Rods for Ship Building / Naval Dock Components photo-1
US$ 9 - 10 MOQ: 1000 Kilograms
Key Specifications
Get Latest Price
Place of Origin:
Gujarat, India
Brand Name:
Shree - Extrusions
Model Number:
C62300 Aluminum Bronze Rods for Ship Building / Naval Dock Components
Contact Supplier Request Quote Chat Now
Shree Extrusions Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Mundra
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Gujarat, India
Brand Name Shree - Extrusions
Model Number C62300 Aluminum Bronze Rods for Ship Building / Naval Dock Components
Application Brass Bars
Diameter 6mm - 250mm
Shape Hexagonal
Length 3 meters up
Grade C360
Cu (Min) As per specification
Alloy Or Not Is Alloy

" C62300 Aluminum Bronze Rods for Ship Building / Naval Dock Components  "



C62300 Aluminum Bronze



C62300 Aluminum Bronze Rods for Ship Building / Naval Dock Components
C62300 Aluminum Bronze

The aluminum bronze C62300 is used while manufacturing valve and pump components for industrial process streams, marine equipment, high strength fasteners and pole line hardware.

Applications :-
  • Fasteners : Nuts, Bolts
  • Industrial : Gears, Bearing Races, Valve Stems, Worm Gears, Valve Guides, Valve Seats, Bearings, Bushings, Cams, Pump Rods
  • Marine: Marine Hardware





Chemical Composition:
  Al Cu Fe Mn Ni Si Sn
Min/Max 8.5 - 10.0 Rem 2.0 - 4.0 0.5 1 0.25 0.6
Nominals 10 87 3 - - - -

Specifications:
End Product Specification
Bar AMS 4635, ASME SB150, ASTM B150, SAE J463, J461
Bar, Forging ASTM B124
Forgings, Die AMS 4635, ASTM B283, MILITARY MIL-B-16166, SAE J463, J461
Rod AMS 4635, ASME SB150, ASTM B150, SAE J463, J461
Rod, Forgings ASTM B124
Shapes ASTM B150
Shapes, Forging ASTM B124

Fabrication:
Joining Technique Suitability
Brazing Fair
Butt Weld Good
Capacity for Being Cold Worked Good
Capacity for Being Hot Formed Good
Coated Metal Arc Welding Good
Forgeability Rating 75
Gas Sheilded Arc Welding Good
Machinability rating 50
Oxyacetylene Welding Not Recommended
Seam Weld Good
Soldering Not Recommended
Spot Weld Good

Physical Properties:
Product Property US Customary Metric
Coefficient of Thermal Expansion 9.0 ·10-6 per oF (68-572 F) 16.2 · 10 6? per °C (20-300 C)
Density 0.277 lb/in3 @ 68 F 7.67 gm/cm3 @ 20 C
Electrical Conductivity 12 %IACS @ 68 F 0.07 MegaSiemens/cm @ 20 C
Electrical Resistivity 86.4 ohms-cmil/ft @ 68 F 14.36 microhm-cm @ 20 C
Melting Point Liquid US 1915 F 1046 C
Melting Point Solid US 1905 F 1041 C
Modulas of Elasticity in Tension 17000 ksi 117000 MPa
Modulas of Rigidity 6400 ksi 44130 MPa
Specific Gravity 7.67 7.67
Specific Heat Capacity 0.09 Btu/lb/°F @ 68 F 377.1 J/kg · °K at 293 K
Thermal Conductivity 31.0 Btu · ft/(hr · ft2 ·°F) @ 68 F 53.7 W/m · °K at 20 C

Sizes Available
ROUND RODS 8mm To 70 mm
HEX 10mm To 60mm
SQUARE 10mm To 60mm
FLAT 10mm Min Thickness and max Width 120mm
BILLETS Up to 200 mm
INGOTS As per Specification
