C36000 Free Machining Brass Rods for Automobiles Part Manufacturers

C36000 Free Machining Brass Rods for Automobiles Part Manufacturers thumbnail-1
C36000 Free Machining Brass Rods for Automobiles Part Manufacturers photo-1
US$ 9 - 10 MOQ: 1000 Kilograms
Key Specifications
Get Latest Price
Place of Origin:
Gujarat, India
Brand Name:
Shree - Extrusions
Model Number:
C36000 Free Machining Brass Rods for Automobiles part manufacturers
Contact Supplier Request Quote Chat Now
Shree Extrusions Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Mundra
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Gujarat, India
Brand Name Shree - Extrusions
Model Number C36000 Free Machining Brass Rods for Automobiles part manufacturers
Application Brass rods
Diameter 6mm - 250mm
Shape Hexagonal
Length 3 meters up
Grade C360
Cu (Min) As per specification
Alloy Or Not Is Alloy



C36000 Free Machining Brass Rods for Automobiles part manufacturers





C36000 Free Machining Brass

C36000 Free Machining Brass is also called Free Cutting Brass. The brass is appreciated for features such as knurling, thread rolling and good machining ability. It is deal for high machining operations with the rating of 100 against all the rated copper alloys. The offered brass can easily be brazed or soldered and is also corrosion resistant.
C36000 Free Machining Brass Rods for Automobiles part manufacturersC36000 Free Machining Brass Rods for Automobiles part manufacturers C36000 Free Machining Brass Rods for Automobiles part manufacturersC36000 Free Machining Brass Rods for Automobiles part manufacturersC36000 Free Machining Brass Rods for Automobiles part manufacturersC36000 Free Machining Brass Rods for Automobiles part manufacturers
C36000 Free Machining Brass Rods for Automobiles part manufacturersC36000 Free Machining Brass Rods for Automobiles part manufacturersC36000 Free Machining Brass Rods for Automobiles part manufacturersC36000 Free Machining Brass Rods for Automobiles part manufacturers
 Applications :
  • Construction Industry: Builders Hardware, Lock Bodies, Hardware, Fittings
  • Consumer: Hot Combs (to Straighten Hair)
  • Fasteners: Bolts, Nuts, Screws
  • Industrial: Faucet Components, Pneumatic Fittings, Fluid Connectors, Automatic Screw Machine Parts, Unions, Adapters, Screw Machine Products, Gauges, Valve Seats, Valve Trim, Valve Stems, Nozzles, Pinions, Gears
  • Plumbing: Plumbers' Brass Goods, Faucet Stems, Faucet Seats, Plumbing Fittings



Equivalent Specifications:
SpecificationsDesignation
ISOCuZn36Pb3
EuropenCuZn36Pb3
JISCZ-124
RussianLS63-3

Chemical Composition:
 CuFePbZn
Min/Max60.0 - 63.00.352.5 - 3.7Rem
Nominals61.5000-3.100035.4000

Specifications:
End ProductSpecification
BarAMS 4610, ASTM B16, SAE J461, J463
RodAMS 4610, ASTM B16, SAE J461, J463
ShapesASTM B16, SAE J461, J463
ValvesMILITARY MIL-V-18436
WireASTM B16

Fabrication:
Joining TechniqueSuitability
BrazingGood
Butt WeldFair
Capacity for Being Cold WorkedFair
Capacity for Being Hot FormedFair
Coated Metal Arc WeldingNot Recommended
Gas Sheilded Arc WeldingNot Recommended
Machinability rating100
Oxyacetylene WeldingNot Recommended
Seam WeldNot Recommended
SolderingExcellent
Spot WeldNot Recommended

Physical Properties:
Product PropertyUS CustomaryMetric
Coefficient of Thermal Expansion11.4 ·10-6 per oF (68-572 F)20.5 · 10 6? per °C (20-300 C)
Density0.307 lb/in3 @ 68 F8.5 gm/cm3 @ 20 C
Electrical Conductivity26 %IACS @ 68 F0.152 MegaSiemens/cm @ 20 C
Electrical Resistivity39.9 ohms-cmil/ft @ 68 F6.63 microhm-cm @ 20 C
Melting Point Liquid US1650 F899 C
Melting Point Solid US1630 F888 C
Modulas of Elasticity in Tension14000 ksi96500 MPa
Modulas of Rigidity5300 ksi36500 MPa
Specific Gravity8.58.5
Thermal Conductivity67.0 Btu · ft/(hr · ft2 ·°F) @ 68 F116.0 W/m · °K at 20 C

Sizes Available
WIRE1mm TO 8 mm
HOLLOW RODSMin Bore Size 20 mm and Max OD 100 mm
ROUND RODS6mm To 130 mm
HEX5mm To 60mm
SQUARE4mm To 60mm
FLAT5mm Min Thickness and max Width 120mm
PROFILES / SECTIONSAS per Customer Drawing
BILLETSUp to 200mm
INGOTSAS per Specification
