Cheapest Plate Heat Transfer Machine Made in China

Cheapest Plate Heat Transfer Machine Made in China thumbnail-1
Cheapest Plate Heat Transfer Machine Made in China photo-1
US$ 98 - 108 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Flatbed Printer
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
Shenzhen Brightness Electronics Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Flatbed Printer
Place of Origin Guangdong, China
Brand Name Brightness
Model Number LDKP1
Automatic Grade Semi-Automatic
Gross Power 400w
Dimensions(L*W*H) 320*200*650mm

Specifications

1Cheapest plate heat press machine
2 easy to operate and light
3 this machine can print image on the plate
4 high quality

Cheapest plate heat press machine



Operation of plate heat press machine

1. plug the three-core power line into the outlet,check whether the power supply is conformity with the rated voltage of the machine, there should be a reliable ground wire for the power supply.

2. put in the object going to be shaped,close up the handle and rotate the adjusting screw to get a proper pressure .

3. turn on the power switch, and the instrument board will display the temperature .

4.set the temperature and time according to the table below and get the

specific corresponding temperature and timing setting.

   initial temperature      highest temperature         time

       355                                               355                     150



5.Close up the pressure handle ,preset the corresponding temperature and timing for the object that is going to be shaped,  it needs a few minutes to achieve the initial heating temperature.

When the temperature achieves the initial heating temperature, it will turn into constant temperature status automatically. Pull up the handle,put into the object and close up the the executive key, then close up the pressure handle,wait for a few times(set),you will hear a hint sound ,the pressing is finished, pull up the pressure handle,press the executive key. do the next object or turn off the power.





size: Net weight : 12kg
Gross weight : 14kg
Dimension :320*200*650mm
Voltage: 220V/110V
Power:450W
Temperature Range:0-380°C
Timing Range:0-999 Sec.
Pressing Size: Diameter 12cm or 15cm
Custom Field: 1.Light weight and portable, for use at malls, flea markets, shows, and more.
2.Fully digital temperature control
3.Automatic digital timer
4.No limit on height of plate,could turn left and right,choose the most suitable place to print
5.Be able to bear high temperature with silica gel,press equal,220°Ccould bear
6.The heating mat could be heated if no plate in the machine
7.Easy pressure adjustment ,Solid steel welded framework
8.An amazing 3-Year/3,000-plate warranty on the heating parts
9.Soft heater liner for accommodating inconsistent plates
10.Temperature readout accuracy +-1C
11.User selectable end-of-cycle alarms
12.Color: Silver Grey
