Specifications
infrared vinyl cutting plottercutting size 620mm
Red Dot positioning, contour cutting
SDcard/ USB
with steel cutter blade
TECHNICAL PARAMETERS of infrared vinyl cutting plotter
vinyl cutting plotter can do contour cutting and contouring on vinyl, adhesive paper, PVC etc.
Model |
LDY720 (24 inches) |
LDY850 (30 inches) |
LDY1100 (40 inches) |
LDY1350 (48 inches) |
Media Way |
M Brackets |
M Brackets |
Stand |
Stand |
Main Board |
High-performance & intelligent ARM 32 CPU ( 200 times faster than 51 chip) |
|||
Control Panel |
16*4 character LCD display, 10 silica gel buttons, easy-to-use and durable |
|||
Driver |
High speed stepping motor, micro-step driver |
|||
Positioning Mode |
Precision electronic Bounded System, random original point setting |
|||
Maximum Paper Feed Width |
720mm |
850mm |
1100mm |
1350mm |
Maximum Cutting Width |
620mm |
750mm |
1000mm |
1250mm |
Maximum Cutting Speed |
650mm/s |
|||
Maximum Cutting Length |
20000mm |
|||
Cutting Force |
0-1000g (digital adjustment) |
|||
Mechanical Precision |
0.05mm |
|||
Repeatable Precision |
< +-0.1mm |
|||
Type of Tool |
Steel cutter blade |
|||
Type of Plot pen |
All types diameter 11. 4mm plotter pen |
|||
Plotter Instruction |
DM-PL/HP-GL Automatic Identification |
|||
Interfaces |
USB/ SD Card / Serial port |
|||
Power Supply |
AC110V /220V±10%, 50Hz/60Hz |
|||
Power |
< 100W |
< 120W |
||
Red Dot Positioning |
Positioning using red dot, contour cutting function; Compatible with FLEXI8, SIGNCUT |
|||
Noise at Work |
≤75 DB |
|||
External Dimension |
112*38*34cm |
125*38*34cm |
150*38*34cm |
175*38*34cm |
Shipping Weight |
26kg |
29kg |
33kg |
36kg |
Features of infrared contour cutting plotter:
1. Use ARM 13 High-performance intelligent controller.
2. Exact positioning using Red Dot, with the registration mark detection to ensure accurate contour cutting.
3. Smooth operation of advanced high-speed cutting function
4. Work independently without connect to computer, high-capacity SD output interface and USB / serial port for diverse choices.
5. Strong cutting pressure, it can cut high-strength grade reflective film material
vinyls for cutter plotter is also available.
